Panasonic lumix DC-TZ90 Basic Operating Instructions

31
DVQX1246 (ENG)
Recording
Adjusting the focus after recording
([Post Focus] / [Focus Stacking])
Recording mode:
You can record 4K burst pictures while changing the focus point and then select a
focus point after recording. This function is best for non-moving subjects.
You can select multiple focus points and combine them into one picture. ([Focus
Stacking])
• To record pictures, use a UHS Speed Class 3 card.
• We recommend using a tripod to perform [Focus Stacking].
1
Press [ ] button
2
Press to select [ON] and press [MENU/SET]
3
Determine the composition and press the
shutter button halfway
• Auto Focus activates and automatically detects the focus point on the screen.
• If there is no focus point on the screen, the Focus indicator (
) blinks and
you cannot record.
From halfway pressing the shutter button to completion of recording
• Do not change the distance to subject or the composition.
4
Press the shutter button fully to start
recording
• The focus point changes automatically while recording. When the recording
progress bar (
) disappears, recording automatically ends.
• The data will be saved as a single file in the MP4 format.
• If Auto Review is set, a screen will automatically appear that lets you select
the focus point. (→32)
■
Cancelling [Post Focus]
Select [OFF] in step
2
.

Panasonic lumix DC-TZ90 Specifications

General

Sensor	1/2.3-inch High Sensitivity MOS Sensor
Effective Pixels	20.3 Megapixels
Lens	LEICA DC VARIO-ELMAR
Dimensions	112.0 x 67.3 x 41.2 mm
Focal Length	4.3 - 129mm (24 - 720mm in 35mm equivalent)
Aperture	F3.3 - F6.4
ISO Sensitivity	80-3200 (expandable to 6400)
Display	3.0-inch TFT Screen LCD Display (1040K dots)
Viewfinder	0.2-inch EVF (1166K dots)
Video Recording	4K UHD (3840x2160) at 30p/25p
Connectivity	Wi-Fi
Battery Life	Approx. 380 shots (CIPA standard)
Weight	Approx. 322g with Battery and SD Memory Card
Storage Media	SD/SDHC/SDXC memory card
Image Stabilization	5-axis Hybrid O.I.S. (Optical Image Stabilizer)
