- 101 -
Connecting to other equipment
Viewing the contents of the built-in memory or card using the PC (folder
composition)
A new folder is created when pictures are taken in the following situations.
When a card containing a folder with the same folder number has been inserted (Such as when
pictures were taken using another maker of camera)
When there is a picture with file number 999 inside the folder
Disconnecting the USB connection cable safely
Proceed with the hardware removal using “Safely Remove Hardware” on the task tray of the
PC. If the icon is not displayed, check that [Access] is not displayed on the LCD monitor of the
digital camera before removing the hardware.
Connection in the PTP Mode (Windows
R
XP, Windows Vista
R
, Windows
R
7 and
Mac OS X only)
Select [PictBridge(PTP)] when connecting USB cable.
Data can now be read only from the card into the PC.
When there are 1000 or more pictures on a card, the pictures may not be imported in the PTP
Mode.
For Windows: A drive ([Removable Disk]) is displayed in [My Computer]
For Macintosh: A drive ([LUMIX], [NO_NAME] or [Untitled]) is displayed on the
desktop
DCIM: Images
1 Folder number
2 File number
3 JPG: Still pictures
MOV: Motion pictures
MISC: DPOF print
Favourite
AD_LUMIX: For Upload set
LUMIXUP.EXE Upload tool
“LUMIX Image
Uploader”
100_PANA
101_PANA
999_PANA
DCIM
MISC
100_PANA

Built-in memory
Card
AD_LUMIX
LUMIXUP.EXE

Table of Contents

Other manuals for Panasonic Lumix DMC-FS18

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-FS18 and is the answer not in the manual?

Panasonic Lumix DMC-FS18 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Image sensor size1/2.33 \
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom4 x
Combined zoom16 x
Focal length range5 - 20 mm
Maximum aperture number6.5
Minimum aperture number3.1
Number of diaphragm blades6
Number of aspheric elements3
Lens structure (elements/groups)6/5
Maximum focal length (35mm film equiv)112 mm
Minimum focal length (35mm film equiv)28 mm
InterfacePAL, USB 2.0
Digital SLRNo
Power source typeBattery
Power supply type3.6 V
Dimensions (WxDxH)94.3 x 18.8 x 53.5 mm
Camera shutter speed8 - 1/1600, 15, 30, 60 s
Focal length (35mm film equivalent)28 - 112 mm
Focus adjustmentAuto
Normal focusing range0.5 m - ∞ [W], 1 m - ∞ [T] m
Auto focusing (AF) modescentre weighted auto focus, continuous auto focus, multi point auto focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.05 - ∞ m
Normal focusing range (wide)0.5 - ∞ m
ISO sensitivity100, 200, 400, 800, 1600, 6400, Auto
Flash modesauto, Flash off, Red-eye reduction
Flash range (tele)1 - 1.6 m
Flash range (wide)0.4 - 3.3 m
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Motion JPEG frame rate30 fps
Maximum video resolution640 x 480 pixels
Field of view100 %
Display diagonal2.7 \
Display resolution (numeric)230000 pixels
Viewfinder typeNot available
USB version2.0
Scene modesBacklight, Beach, Candlelight, Children, Close-up (macro), Cuisine, Documents, Fireworks, Landscape (scenery), Museum, Night landscape, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sunset
Photo effectsBlack&White, Neutral, Sepia, Vivid
White balanceAuto, Cloudy, Custom modes, Daylight, Incandescent, Shade
Camera playbackmovie, single image, slide show, thumbnails
Self-timer delay2 s
Product colorSilver
Battery capacity660 mAh
Battery life (CIPA standard)260 shots
Cables includedAC, AV, USB
Bundled softwarePHOTOfunSTUDIO 6.0 / QuickTime / Adobe Reader
Fastest camera shutter speed1/1600 s
Slowest camera shutter speed8 s
Weight and Dimensions IconWeight and Dimensions
Depth18.8 mm
Width94.3 mm
Height53.5 mm
Weight121 g
