Page #120 background imageLoading...
Page #120 background image
Others
- 120 -
Troubleshooting
First, try out the following procedures (P120127).
The battery is exhausted. Charge the battery.
If you leave the camera on, the battery will be exhausted.
> Turn the camera off frequently by using the [Sleep Mode] Mode etc. (P38)
Is the [Rec]/[Playback] selector switch at the [!] setting? (P21)
Is there any memory remaining on the built-in memory or the card?
> Delete the pictures which are not necessary to increase the available memory. (P33)
The picture can become whitish if there is dirt e.g. fingerprints on the lens.
> If the lens is dirty, turn on the camera, eject the lens barrel and gently wipe the lens surface
with a soft dry cloth.
> Check that the exposure is correctly compensated. (P53)
> Set [Burst] (P79) of the [Rec] Mode menu to [OFF].
Has [Hi-Speed Burst] (P63) or [Flash Burst] (P64) in Scene Mode been set?
The focus range varies depending on the Recording Mode.
> Set to the proper mode for the distance to the subject.
The subject is beyond the focus range of the camera. (P26)
There is camera shake (jitter) or the subject is moving slightly. (P25)
If the problem is not resolved, it may be improved by selecting [Reset] (P39) on the
[Setup] menu.
Battery and power source
The camera cannot be operated even when it is turned on.
The camera turns off immediately after it is turned on.
Recording
The picture cannot be recorded.
The recorded picture is whitish.
The recorded picture is too bright or dark.
Multiple pictures are taken at one time.
The subject is not focused properly.

Table of Contents

Other manuals for Panasonic Lumix DMC-FS18

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-FS18 and is the answer not in the manual?

Panasonic Lumix DMC-FS18 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Image sensor size1/2.33 \
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom4 x
Combined zoom16 x
Focal length range5 - 20 mm
Maximum aperture number6.5
Minimum aperture number3.1
Number of diaphragm blades6
Number of aspheric elements3
Lens structure (elements/groups)6/5
Maximum focal length (35mm film equiv)112 mm
Minimum focal length (35mm film equiv)28 mm
InterfacePAL, USB 2.0
Digital SLRNo
Power source typeBattery
Power supply type3.6 V
Dimensions (WxDxH)94.3 x 18.8 x 53.5 mm
Camera shutter speed8 - 1/1600, 15, 30, 60 s
Focal length (35mm film equivalent)28 - 112 mm
Focus adjustmentAuto
Normal focusing range0.5 m - ∞ [W], 1 m - ∞ [T] m
Auto focusing (AF) modescentre weighted auto focus, continuous auto focus, multi point auto focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.05 - ∞ m
Normal focusing range (wide)0.5 - ∞ m
ISO sensitivity100, 200, 400, 800, 1600, 6400, Auto
Flash modesauto, Flash off, Red-eye reduction
Flash range (tele)1 - 1.6 m
Flash range (wide)0.4 - 3.3 m
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Motion JPEG frame rate30 fps
Maximum video resolution640 x 480 pixels
Field of view100 %
Display diagonal2.7 \
Display resolution (numeric)230000 pixels
Viewfinder typeNot available
USB version2.0
Scene modesBacklight, Beach, Candlelight, Children, Close-up (macro), Cuisine, Documents, Fireworks, Landscape (scenery), Museum, Night landscape, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sunset
Photo effectsBlack&White, Neutral, Sepia, Vivid
White balanceAuto, Cloudy, Custom modes, Daylight, Incandescent, Shade
Camera playbackmovie, single image, slide show, thumbnails
Self-timer delay2 s
Product colorSilver
Battery capacity660 mAh
Battery life (CIPA standard)260 shots
Cables includedAC, AV, USB
Bundled softwarePHOTOfunSTUDIO 6.0 / QuickTime / Adobe Reader
Fastest camera shutter speed1/1600 s
Slowest camera shutter speed8 s
Weight and Dimensions IconWeight and Dimensions
Depth18.8 mm
Width94.3 mm
Height53.5 mm
Weight121 g
