Panasonic Lumix DMC-FS18 User Manual

- 89 -
Playback/Editing
[Playback] Mode: ¸
Using the [Playback] Mode Menu
You can set up pictures to be uploaded to image sharing sites and perform actions like
cropping recorded pictures, as well as set up the protection of recorded images, etc.
• With [Text Stamp], [Resize] or [Cropping], a new edited picture is created. A new picture cannot
be created if there is no free space on the built-in memory or the card so we recommend
checking that there is free space and then editing the picture.
It is possible to setup the images to be uploaded to the image sharing sites (Facebook/You
Tube) on this unit.
• You can only upload still pictures to Facebook, and only motion pictures to YouTube.
• This cannot be done to the images in the built-in memory. Copy the images to a card
(P98), and then perform the [Upload Set].
Select [Upload Set] on the [Playback] Mode menu. (P35)
Press 3/4 to select [SINGLE] or [MULTI] and then press [MENU/
SET].
∫ Upload to the image sharing sites
An upload tool built-in to the camera “LUMIX Image Uploader” is automatically copied to
the card when you setup [Upload Set].
Perform the upload operation after connecting the camera to a PC (P99). For details, refer
to P102.
∫ Cancelling all the [Upload Set] settings
1 Select [Upload Set] on the [Playback] Mode menu.
2 Press 3/4 to select [CANCEL] and then press [MENU/SET].
• Confirmation screen is displayed. It is executed when [Yes] is selected.
Exit the menu after it is executed.
Note
• Setting may not be possible for pictures recorded with other cameras.
• It cannot be set with the card less than 512 MB.
[Upload Set]
Select the picture, and then press
[MENU/SET] to set.
[MULTI] setting
Press [DISP.] to set (repeat), and then
press [MENU/SET] to set.
• The setting is cancelled when [DISP.] is
pressed again.
• Exit the menu after it is set.
• Confirmation screen is displayed. It is
executed when [Yes] is selected.
Exit the menu after it is executed.
[SINGLE] [MULTI]
Press 2/1 to
select the picture.
Press 3/4/2/1 to
select the pictures.

Panasonic Lumix DMC-FS18 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.33 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom	4 x
Combined zoom	16 x
Focal length range	5 - 20 mm
Maximum aperture number	6.5
Minimum aperture number	3.1
Number of diaphragm blades	6
Number of aspheric elements	3
Lens structure (elements/groups)	6/5
Maximum focal length (35mm film equiv)	112 mm
Minimum focal length (35mm film equiv)	28 mm
Interface	PAL, USB 2.0
Digital SLR	No
Power source type	Battery
Power supply type	3.6 V
Dimensions (WxDxH)	94.3 x 18.8 x 53.5 mm
Camera shutter speed	8 - 1/1600, 15, 30, 60 s
Focal length (35mm film equivalent)	28 - 112 mm
Focus adjustment	Auto
Normal focusing range	0.5 m - ∞ [W], 1 m - ∞ [T] m
Auto focusing (AF) modes	centre weighted auto focus, continuous auto focus, multi point auto focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.05 - ∞ m
Normal focusing range (wide)	0.5 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600, 6400, Auto
Flash modes	auto, Flash off, Red-eye reduction
Flash range (tele)	1 - 1.6 m
Flash range (wide)	0.4 - 3.3 m
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Motion JPEG frame rate	30 fps
Maximum video resolution	640 x 480 pixels
Field of view	100 %
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
Viewfinder type	Not available
USB version	2.0
Scene modes	Backlight, Beach, Candlelight, Children, Close-up (macro), Cuisine, Documents, Fireworks, Landscape (scenery), Museum, Night landscape, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sunset
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Incandescent, Shade
Camera playback	movie, single image, slide show, thumbnails
Self-timer delay	2 s
Product color	Silver
Battery capacity	660 mAh
Battery life (CIPA standard)	260 shots
Cables included	AC, AV, USB
Bundled software	PHOTOfunSTUDIO 6.0 / QuickTime / Adobe Reader
Fastest camera shutter speed	1/1600 s
Slowest camera shutter speed	8 s

Weight and Dimensions

Depth	18.8 mm
Width	94.3 mm
Height	53.5 mm
Weight	121 g
