Basic
- 22 -
[Rec] Mode: ñ
Taking pictures using the automatic function
(Intelligent Auto Mode)
The camera will set the most appropriate settings to match the subject and the recording
conditions so we recommend this mode for beginners or those who want to leave the
settings to the camera and take pictures easily.
The following functions are activated automatically.
Scene Detection/[Stabilizer]/Face Detection/Motion Detection/[i.Exposure]/
Backlight Compensation/[Red-Eye Removal]/[i.Resolution]/[i.ZOOM]/Auto White Balance/
[AF Assist Lamp]
Slide the [Rec]/[Playback] selector
switch to [!], and then press
[MODE].
Press 3/4/2/1 to select [Intelligent Auto],
and then press [MENU/SET].
Press the shutter button halfway to focus.
The focus indication 1 (green) lights when the subject
is focused.
The AF area 2 is displayed around the subject’s face
by the Face Detection function. In other cases, it is
displayed at the point on the subject which is in focus.
The minimal distance (how close you can be to the
subject) will change depending on the zoom factor.
Please check with the recordable range display on
the screen.
(P26)
You can set the AF tracking by pressing 3. For details,
refer to P77. (AF tracking is cancelled by pressing 3
again)
Press the shutter button fully (push it in
further), and take the picture.
1
2

Table of Contents

Other manuals for Panasonic Lumix DMC-FS18

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-FS18 and is the answer not in the manual?

Panasonic Lumix DMC-FS18 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Image sensor size1/2.33 \
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom4 x
Combined zoom16 x
Focal length range5 - 20 mm
Maximum aperture number6.5
Minimum aperture number3.1
Number of diaphragm blades6
Number of aspheric elements3
Lens structure (elements/groups)6/5
Maximum focal length (35mm film equiv)112 mm
Minimum focal length (35mm film equiv)28 mm
InterfacePAL, USB 2.0
Digital SLRNo
Power source typeBattery
Power supply type3.6 V
Dimensions (WxDxH)94.3 x 18.8 x 53.5 mm
Camera shutter speed8 - 1/1600, 15, 30, 60 s
Focal length (35mm film equivalent)28 - 112 mm
Focus adjustmentAuto
Normal focusing range0.5 m - ∞ [W], 1 m - ∞ [T] m
Auto focusing (AF) modescentre weighted auto focus, continuous auto focus, multi point auto focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.05 - ∞ m
Normal focusing range (wide)0.5 - ∞ m
ISO sensitivity100, 200, 400, 800, 1600, 6400, Auto
Flash modesauto, Flash off, Red-eye reduction
Flash range (tele)1 - 1.6 m
Flash range (wide)0.4 - 3.3 m
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Motion JPEG frame rate30 fps
Maximum video resolution640 x 480 pixels
Field of view100 %
Display diagonal2.7 \
Display resolution (numeric)230000 pixels
Viewfinder typeNot available
USB version2.0
Scene modesBacklight, Beach, Candlelight, Children, Close-up (macro), Cuisine, Documents, Fireworks, Landscape (scenery), Museum, Night landscape, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sunset
Photo effectsBlack&White, Neutral, Sepia, Vivid
White balanceAuto, Cloudy, Custom modes, Daylight, Incandescent, Shade
Camera playbackmovie, single image, slide show, thumbnails
Self-timer delay2 s
Product colorSilver
Battery capacity660 mAh
Battery life (CIPA standard)260 shots
Cables includedAC, AV, USB
Bundled softwarePHOTOfunSTUDIO 6.0 / QuickTime / Adobe Reader
Fastest camera shutter speed1/1600 s
Slowest camera shutter speed8 s
Weight and Dimensions IconWeight and Dimensions
Depth18.8 mm
Width94.3 mm
Height53.5 mm
Weight121 g
