Panasonic Lumix DMC-FS18 User Manual

Preparation
- 18 -
∫ About the display of the number of recordable pictures and available recording time
∫ Number of recordable pictures
•[i99999] is displayed if there are more than 100,000 pictures remaining.
(DMC-FS35) (DMC-FS18)
(DMC-FS16) (DMC-FS14)
∫ Available recording time (when recording motion pictures)
(DMC-FS35) (DMC-FS18)
(DMC-FS16) (DMC-FS14)
• The number of recordable pictures and the available recording time are an approximation.
(These vary depending on the recording conditions and the type of card.)
• The number of recordable pictures and the available recording time varies depending on the
subjects.
• Number of recordable pictures/available recording time for the card may decrease when
[Upload Set] is performed.
• Motion pictures can be recorded continuously for up to 15 minutes. Also, continuous recording
exceeding 2 GB is not possible. (Example: (DMC-FS35) (DMC-FS18) [10m10s], (DMC-FS16)
(DMC-FS14) [8m10s] with [ ])
Remaining time for continuous recording is displayed on the screen.
Approximate number of recordable pictures and available recording time
A Number of recordable pictures
B Available recording time
when taking still
pictures
when recording
motion pictures
Picture size
Built-in Memory
(Approx. 70 MB)
2GB 4GB 16 GB
16M (4:3) 11 300 600 2450
5M (4:3) 26 650 1300 5300
0.3M (4:3) 410 10050 19940 81340
Picture size
Built-in Memory
(Approx. 70 MB)
2GB 4GB 16 GB
14M (4:3) 13 330 670 2740
5M (4:3) 26 650 1300 5300
0.3M (4:3) 410 10050 19940 81340
Recording
quality setting
Built-in Memory
(Approx. 70 MB)
2GB 4GB 16 GB
HD j 10 min 10 s 20 min 30 s 1 h 23 min
VGA j 21 min 40 s 43 min 10 s 2 h 56 min
QVGA 2 min 30 s 1 h 2 min 2 h 4 min 8 h 28 min
Recording
quality setting
Built-in Memory
(Approx. 70 MB)
2GB 4GB 16 GB
HD j 8 min 10 s 16 min 20 s 1 h 7 min
VGA j 21 min 40 s 43 min 10 s 2 h 56 min
QVGA 2 min 30 s 1 h 2 min 2 h 4 min 8 h 28 min
A
B

Panasonic Lumix DMC-FS18 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.33 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom	4 x
Combined zoom	16 x
Focal length range	5 - 20 mm
Maximum aperture number	6.5
Minimum aperture number	3.1
Number of diaphragm blades	6
Number of aspheric elements	3
Lens structure (elements/groups)	6/5
Maximum focal length (35mm film equiv)	112 mm
Minimum focal length (35mm film equiv)	28 mm
Interface	PAL, USB 2.0
Digital SLR	No
Power source type	Battery
Power supply type	3.6 V
Dimensions (WxDxH)	94.3 x 18.8 x 53.5 mm
Camera shutter speed	8 - 1/1600, 15, 30, 60 s
Focal length (35mm film equivalent)	28 - 112 mm
Focus adjustment	Auto
Normal focusing range	0.5 m - ∞ [W], 1 m - ∞ [T] m
Auto focusing (AF) modes	centre weighted auto focus, continuous auto focus, multi point auto focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.05 - ∞ m
Normal focusing range (wide)	0.5 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600, 6400, Auto
Flash modes	auto, Flash off, Red-eye reduction
Flash range (tele)	1 - 1.6 m
Flash range (wide)	0.4 - 3.3 m
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Motion JPEG frame rate	30 fps
Maximum video resolution	640 x 480 pixels
Field of view	100 %
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
Viewfinder type	Not available
USB version	2.0
Scene modes	Backlight, Beach, Candlelight, Children, Close-up (macro), Cuisine, Documents, Fireworks, Landscape (scenery), Museum, Night landscape, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sunset
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Incandescent, Shade
Camera playback	movie, single image, slide show, thumbnails
Self-timer delay	2 s
Product color	Silver
Battery capacity	660 mAh
Battery life (CIPA standard)	260 shots
Cables included	AC, AV, USB
Bundled software	PHOTOfunSTUDIO 6.0 / QuickTime / Adobe Reader
Fastest camera shutter speed	1/1600 s
Slowest camera shutter speed	8 s

Weight and Dimensions

Depth	18.8 mm
Width	94.3 mm
Height	53.5 mm
Weight	121 g
