Panasonic Lumix DMC-FS18 User Manual

- 17 -
Preparation
The following cards, which conform to the SD video standard, can be used with this unit.
(These cards are indicated as card in the text.)
¢ SD Speed Class is the speed standard regarding continuous writing. Check via the label on
the card, etc.
• Please confirm the latest information on the following website.
http://panasonic.jp/support/global/cs/dsc/
(This site is English only.)
Note
• Do not turn this unit off, remove its battery or card, or disconnect the AC Adaptor
(optional) when the access indication is lit (when pictures are being written, read or
deleted, or the built-in memory or the card is being formatted). Furthermore, do not
subject the camera to vibration, impact or static electricity.
The card or the data on the card may be damaged, and this unit may no longer operate
normally.
If operation fails due to vibration, impact or static electricity, try using it again.
• Write-Protect switch
A provided (When this switch is set to the [LOCK] position,
no further data writing, deletion or formatting is possible. The ability to write, delete
and format data is restored when the switch is returned to its original position.)
• The data on the built-in memory or the card may be damaged or lost due to
electromagnetic waves, static electricity or breakdown of the camera or the card.
We recommend storing important data on a PC etc.
• Do not format the card on your PC or other equipment. Format it on the camera
only to ensure proper operation. (P40)
• Keep the Memory Card out of reach of children to prevent swallowing.
Card
Type of card which can be
used with this unit
Remarks
SD Memory Card
(8 MB to 2 GB)
• Use a card with SD Speed Class
¢
with “Class 6” or
higher when recording motion pictures.
• SDHC Memory Card can be used with SDHC Memory Card
or SDXC Memory Card compatible equipment.
• SDXC Memory Card can only be used with SDXC Memory
Card compatible equipment.
• Check that the PC and other equipment are compatible when
using the SDXC Memory Cards.
http://panasonic.net/avc/sdcard/information/SDXC.html
• Only the cards with capacity listed left can be used.
SDHC Memory Card
(4 GB to 32 GB)
SDXC Memory Card
(48 GB, 64 GB)
e.g.:
2
A

Panasonic Lumix DMC-FS18 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.33 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom	4 x
Combined zoom	16 x
Focal length range	5 - 20 mm
Maximum aperture number	6.5
Minimum aperture number	3.1
Number of diaphragm blades	6
Number of aspheric elements	3
Lens structure (elements/groups)	6/5
Maximum focal length (35mm film equiv)	112 mm
Minimum focal length (35mm film equiv)	28 mm
Interface	PAL, USB 2.0
Digital SLR	No
Power source type	Battery
Power supply type	3.6 V
Dimensions (WxDxH)	94.3 x 18.8 x 53.5 mm
Camera shutter speed	8 - 1/1600, 15, 30, 60 s
Focal length (35mm film equivalent)	28 - 112 mm
Focus adjustment	Auto
Normal focusing range	0.5 m - ∞ [W], 1 m - ∞ [T] m
Auto focusing (AF) modes	centre weighted auto focus, continuous auto focus, multi point auto focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.05 - ∞ m
Normal focusing range (wide)	0.5 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600, 6400, Auto
Flash modes	auto, Flash off, Red-eye reduction
Flash range (tele)	1 - 1.6 m
Flash range (wide)	0.4 - 3.3 m
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Motion JPEG frame rate	30 fps
Maximum video resolution	640 x 480 pixels
Field of view	100 %
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
Viewfinder type	Not available
USB version	2.0
Scene modes	Backlight, Beach, Candlelight, Children, Close-up (macro), Cuisine, Documents, Fireworks, Landscape (scenery), Museum, Night landscape, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sunset
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Incandescent, Shade
Camera playback	movie, single image, slide show, thumbnails
Self-timer delay	2 s
Product color	Silver
Battery capacity	660 mAh
Battery life (CIPA standard)	260 shots
Cables included	AC, AV, USB
Bundled software	PHOTOfunSTUDIO 6.0 / QuickTime / Adobe Reader
Fastest camera shutter speed	1/1600 s
Slowest camera shutter speed	8 s

Weight and Dimensions

Depth	18.8 mm
Width	94.3 mm
Height	53.5 mm
Weight	121 g
