Panasonic Lumix DMC-FS18 User Manual

- 119 -
Others
[Please turn camera off and then on again]/[System Error]
• This message appears when the camera is not operating properly.
> Turn the camera off and on. If the message persists, contact the dealer or your nearest
Service Centre.
[Memory card parameter error]/[This memory card cannot be used]
> Use a card compatible with this unit. (P17)
– SD Memory Card (8 MB to 2 GB)
– SDHC Memory Card (4 GB to 32 GB)
– SDXC Memory Card (48 GB, 64 GB)
[Insert SD card again]/[Try another card]
• An error has occurred accessing the card.
> Insert the card again.
> Insert a different card.
[Read Error/Write Error
Please check the card]
• It has failed to read or write data.
> Remove the card after turning the power [OFF]. Insert the card again, turn the power on,
and try to read or write the data again.
• The card may be broken.
> Insert a different card.
[Motion recording was cancelled due to the limitation of the writing speed of the
card]
• Use a card with SD Speed Class with “Class 6” or higher when recording motion pictures.
• In the event that it stops even after using a “Class 6” card or higher, the data writing speed has
deteriorated so it is recommended to make a backup and then format (P40).
• Depending on the type of the card, motion picture recording may stop in the middle.
[A folder cannot be created]
• A folder cannot be created because there are no remaining folder numbers that can be used.
> Format the card after saving necessary data on a PC etc. (P40)
[Picture is displayed for 16:9 TV]/[Picture is displayed for 4:3 TV]
• Select [TV Aspect] in the [Setup] menu if you want to change the TV aspect. (P39)
• This message also appears when the USB connection cable is connected to the camera only.
In this case, connect the other end of the USB connection cable to a PC or a printer. (P99,
103)

Panasonic Lumix DMC-FS18 Specifications

General

Megapixel	16.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.33 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4608 x 3456 pixels
Still image resolution(s)	640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom	4 x
Combined zoom	16 x
Focal length range	5 - 20 mm
Maximum aperture number	6.5
Minimum aperture number	3.1
Number of diaphragm blades	6
Number of aspheric elements	3
Lens structure (elements/groups)	6/5
Maximum focal length (35mm film equiv)	112 mm
Minimum focal length (35mm film equiv)	28 mm
Interface	PAL, USB 2.0
Digital SLR	No
Power source type	Battery
Power supply type	3.6 V
Dimensions (WxDxH)	94.3 x 18.8 x 53.5 mm
Camera shutter speed	8 - 1/1600, 15, 30, 60 s
Focal length (35mm film equivalent)	28 - 112 mm
Focus adjustment	Auto
Normal focusing range	0.5 m - ∞ [W], 1 m - ∞ [T] m
Auto focusing (AF) modes	centre weighted auto focus, continuous auto focus, multi point auto focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.05 - ∞ m
Normal focusing range (wide)	0.5 - ∞ m
ISO sensitivity	100, 200, 400, 800, 1600, 6400, Auto
Flash modes	auto, Flash off, Red-eye reduction
Flash range (tele)	1 - 1.6 m
Flash range (wide)	0.4 - 3.3 m
Internal memory	70 MB
Compatible memory cards	SD, SDHC, SDXC
Motion JPEG frame rate	30 fps
Maximum video resolution	640 x 480 pixels
Field of view	100 %
Display diagonal	2.7 \
Display resolution (numeric)	230000 pixels
Viewfinder type	Not available
USB version	2.0
Scene modes	Backlight, Beach, Candlelight, Children, Close-up (macro), Cuisine, Documents, Fireworks, Landscape (scenery), Museum, Night landscape, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sunset
Photo effects	Black&White, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Incandescent, Shade
Camera playback	movie, single image, slide show, thumbnails
Self-timer delay	2 s
Product color	Silver
Battery capacity	660 mAh
Battery life (CIPA standard)	260 shots
Cables included	AC, AV, USB
Bundled software	PHOTOfunSTUDIO 6.0 / QuickTime / Adobe Reader
Fastest camera shutter speed	1/1600 s
Slowest camera shutter speed	8 s

Weight and Dimensions

Depth	18.8 mm
Width	94.3 mm
Height	53.5 mm
Weight	121 g
