Others
- 114 -
Before cleaning the camera, remove the battery or the DC coupler (optional), or
disconnect the power plug from the outlet. Then wipe the camera with a dry soft
cloth.
When the camera is soiled badly, it can be cleaned by wiping the dirt off with a wrung wet cloth,
and then with a dry cloth.
Do not use solvents such as benzine, thinner, alcohol, kitchen or detergents, etc., to clean the
camera, since it may deteriorate the external case or the coating may peel off.
When using a chemical cloth, be sure to follow the accompanying instructions.
If the LCD monitor is dirty, blow away dust and foreign matter with a commercial blower brush.
If it is very dirty, gently rub with a soft cloth or an eyeglass cloth.
Do not press the LCD monitor with excessive force. Uneven colours may appear on the LCD
monitor and it may malfunction.
Do not press on the LCD monitor with hard pointed tips, such as ballpoint pens.
Do not scratch or press the LCD monitor too hard.
If the camera is cold when you turn it on, the picture on the LCD monitor will be slightly darker
than usual at first. However, the picture will return to normal brightness when the internal
temperature of the camera increases.
Do not press the lens with excessive force.
Do not leave the camera with the lens facing the sun, as rays of light from the sun may cause it
to malfunction. Also, be careful when placing the camera outside or near a window.
Cleaning
About the LCD monitor
Extremely high precision technology is employed to produce the LCD monitor screen.
However, there may be some dark or bright spots (red, blue or green) on the screen.
This is not a malfunction. The LCD monitor screen has more than 99.99% effective
pixels with a mere 0.01% of the pixels inactive or always lit. The spots will not be
recorded on pictures on the built-in memory or a card.
About the Lens

Table of Contents

Other manuals for Panasonic Lumix DMC-FS18

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-FS18 and is the answer not in the manual?

Panasonic Lumix DMC-FS18 Specifications

General IconGeneral
Megapixel16.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Image sensor size1/2.33 \
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)640 x 480, 2048 x 1536, 2560 x 1920, 3648 x 2736, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom4 x
Combined zoom16 x
Focal length range5 - 20 mm
Maximum aperture number6.5
Minimum aperture number3.1
Number of diaphragm blades6
Number of aspheric elements3
Lens structure (elements/groups)6/5
Maximum focal length (35mm film equiv)112 mm
Minimum focal length (35mm film equiv)28 mm
InterfacePAL, USB 2.0
Digital SLRNo
Power source typeBattery
Power supply type3.6 V
Dimensions (WxDxH)94.3 x 18.8 x 53.5 mm
Camera shutter speed8 - 1/1600, 15, 30, 60 s
Focal length (35mm film equivalent)28 - 112 mm
Focus adjustmentAuto
Normal focusing range0.5 m - ∞ [W], 1 m - ∞ [T] m
Auto focusing (AF) modescentre weighted auto focus, continuous auto focus, multi point auto focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.05 - ∞ m
Normal focusing range (wide)0.5 - ∞ m
ISO sensitivity100, 200, 400, 800, 1600, 6400, Auto
Flash modesauto, Flash off, Red-eye reduction
Flash range (tele)1 - 1.6 m
Flash range (wide)0.4 - 3.3 m
Internal memory70 MB
Compatible memory cardsSD, SDHC, SDXC
Motion JPEG frame rate30 fps
Maximum video resolution640 x 480 pixels
Field of view100 %
Display diagonal2.7 \
Display resolution (numeric)230000 pixels
Viewfinder typeNot available
USB version2.0
Scene modesBacklight, Beach, Candlelight, Children, Close-up (macro), Cuisine, Documents, Fireworks, Landscape (scenery), Museum, Night landscape, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sunset
Photo effectsBlack&White, Neutral, Sepia, Vivid
White balanceAuto, Cloudy, Custom modes, Daylight, Incandescent, Shade
Camera playbackmovie, single image, slide show, thumbnails
Self-timer delay2 s
Product colorSilver
Battery capacity660 mAh
Battery life (CIPA standard)260 shots
Cables includedAC, AV, USB
Bundled softwarePHOTOfunSTUDIO 6.0 / QuickTime / Adobe Reader
Fastest camera shutter speed1/1600 s
Slowest camera shutter speed8 s
Weight and Dimensions IconWeight and Dimensions
Depth18.8 mm
Width94.3 mm
Height53.5 mm
Weight121 g
