S-29
S5.1.2. Main P.C.B. Address Information
Address Information
C.....Component Side
F......Foil Side
Integrated Circuit
IC1001 E-9 F
IC1210 E-7 F
IC2001 E-7 F
IC3001 D-10 F
IC3002 E-2 C
IC6001 B-9 F
IC6002 C-2 C
IC7101 E-8 F
IC9101 C-8 F
Transistor
Q1040 E-7 F
Q1050 F-9 F
Q1070 E-2 C
Q1071 E-2 C
Q1101 F-5 C
Q1102 E-5 C
Transistor-resistor
QR1101 E-9 F
QR1102 D-7 F
QR6001 D-9 F
QR7131 D-3 C
Test Point
CL1001 F-8 F
CL1002 E-5 C
CL1003 D-9 F
CL1004 C-7 F
CL1005 E-9 F
CL1006 E-9 F
CL1007 E-2 C
CL1010 B-10 F
CL1020 E-8 F
CL1030 C-10 F
CL1040 C-10 F
CL1050 D-10 F
CL1060 E-9 F
CL1070 D-3 C
CL1071 D-3 C
CL1210 E-7 F
CL1220 F-2 C
CL2001 D-7 F
CL2004 C-7 F
CL2005 D-5 C
CL2007 D-7 F
CL2008 D-7 F
CL2012 D-7 F
CL3004 E-2 C
CL3005 E-2 C
CL3007 E-3 C
CL5001 E-3 C
CL5002 E-5 C
CL5003 E-5 C
CL5006 B-8 F
CL6001 B-3 C
CL6002 B-3 C
CL6003 B-3 C
CL6004 B-3 C
CL6005 B-2 C
CL6006 B-10 F
CL7001 B-3 C
CL7002 B-3 C
CL9001 E-2 C
CL9002 E-5 C
CL9003 D-5 C
CL9101 C-8 F
RL1070 C-10 F
RL3001 D-10 F
RL5001 C-2 C
RL6001 C-10 F
RL6002 C-10 F
RL6003 B-2 C
RL6004 B-2 C
RL6005 B-3 C
RL6007 B-3 C
RL6008 B-3 C
RL6009 B-3 C
RL6010 B-3 C
RL6011 C-2 C
RL6012 C-2 C
RL6013 C-2 C
RL7006 C-8 F
RL7007 C-8 F
RL9104 E-4 C
RL9106 E-3 C
TL2001 B-6 F
Connector
FP9001 E-3 C
FP9002 B-4 C
FP9004 D-4 C
FP9005 E-5 C
FP9103 E-4 C
JK2001 D-7 F
JK2002 C-7 F
PP9001 F-9 F
Fuse
F2001 C-7 F
Diode
D1050 F-10 F
D1051 F-2 C
D1060 E-9 F
D1070 E-10 F
D1071 F-2 C
D1101 F-7 F
D1102 E-8 F
D1103 F-7 F
D3001 F-3 C
D9101 B-7 F
D9501 D-4 C
Crystal Oscillator
X6001 B-8 F
X9101 C-7 F
Coil
L1010 E-7 F
L1020 E-8 F
L1030 E-8 F
L1040 F-7 F
L1050 F-9 F
L1060 E-9 F
L1070 F-10 F
L2002 E-7 F
L3001 F-3 C
L3003 D-9 F
L3004 D-9 F
L6002 B-8 F
L7001 B-8 F
L7101 E-8 F
LB2001 D-7 F
LB2002 D-5 C
LB2003 D-7 F
LB2004 C-7 F
LB2005 C-7 F
LB2006 D-7 F
LB2008 C-7 F
LB2009 D-7 F
LB3001 D-10 F
LB3006 D-10 F
LB3042 D-2 C
LB3043 D-2 C
LB6001 C-9 F
LB6002 C-9 F
LB6003 C-9 F
Capacitor
C1001 F-8 F
C1002 F-8 F
C1003 D-8 F
C1004 D-9 F
C1005 D-9 F
C1006 D-9 F
C1007 D-9 F
C1008 D-9 F
C1010 E-7 F
C1020 E-8 F
C1021 D-8 F
C1022 D-8 F
C1030 E-8 F
C1040 E-7 F
C1041 E-8 F
C1050 F-3 C
C1051 D-9 F
C1054 F-3 C
C1056 F-9 F
C1060 E-9 F
C1061 D-9 F
C1070 E-9 F
C1071 E-2 C
C1211 E-7 F
C1212 E-7 F
C2001 E-7 F
C2002 E-7 F
C2003 E-6 F
C2004 E-7 F
C2007 D-5 C
C2008 D-5 C
C3001 F-3 C
C3002 F-3 C
C3003 D-10 F
C3004 E-10 F
C3005 E-10 F
C3008 D-10 F
C3009 D-10 F
C3011 D-9 F
C3012 D-3 C
C3013 D-2 C
C3014 E-2 C
C3015 E-2 C
C3016 E-10 F
C3021 E-2 C
C3023 E-10 F
C3024 E-10 F
C3025 E-9 F
C3026 D-2 C
C3030 D-3 C
C3031 E-9 F
C3032 D-10 F
C3036 D-3 C
C4102 E-4 C
C4103 D-3 C
C4104 E-4 C
C4105 E-3 C
C4106 E-4 C
C4107 F-3 C
C4108 F-4 C
C4109 F-4 C
C4110 F-4 C
C4111 F-4 C
C4112 F-4 C
C4113 F-4 C
C4114 E-4 C
C4115 F-3 C
C5001 B-7 F
C5002 B-7 F
C5003 B-7 F
C5004 B-7 F
C5005 B-7 F
C5006 B-7 F
C5007 B-7 F
C5009 B-7 F
C5010 C-7 F
C5011 B-7 F
C5012 B-7 F
C6001 C-2 C
C6002 C-3 C
C6012 C-3 C
C6013 C-9 F
C6015 B-9 F
C6016 D-9 F
C6021 B-9 F
C6022 B-9 F
C6101 B-8 F
C6102 B-10 F
C6103 C-9 F
C6106 B-10 F
C6107 C-10 F
C6108 B-10 F
C6109 B-8 F
C6111 C-2 C
C6113 B-8 F
C6115 B-8 F
C6117 C-9 F
C6118 C-10 F
C6119 C-10 F
C6120 B-10 F
C6121 B-10 F
C6123 B-10 F
C6125 B-10 F
C6128 C-10 F
C6130 C-10 F
C6131 B-10 F
C6132 B-10 F
C6133 B-8 F
C6134 B-9 F
C6156 B-8 F
C6157 C-9 F
C6158 B-3 C
C6160 B-8 F
C6161 B-8 F
C6162 D-8 F
C6163 D-8 F
C6164 B-9 F
C6165 D-8 F
C6166 D-8 F
C7001 B-8 F
C7002 C-4 C
C7003 B-4 C
C7004 B-8 F
C7005 B-7 F
C7006 C-8 F
C7013 C-8 F
C7014 B-4 C
C7015 B-4 C
C7016 C-8 F
C7017 C-4 C
C7018 C-4 C
C7019 C-8 F
C7022 C-8 F
C7023 B-4 C
C7024 B-5 C
C7101 E-8 F
C7102 D-8 F
C7103 D-7 F
C7106 D-8 F
C7107 D-7 F
C7108 E-8 F
C7109 D-7 F
C7110 D-7 F
C7111 D-7 F
C7112 D-8 F
C9001 E-4 C
C9101 C-7 F
C9102 C-7 F
C9103 C-7 F
C9104 B-7 F
C9105 C-7 F
C9106 B-7 F
C9108 B-7 F
C9109 B-7 F
C9110 C-8 F
C9111 B-7 F
CX6001 B-8 F
CX6002 B-8 F
Resistor
R1001 D-9 F
R1010 D-8 F
R1011 D-8 F
R1012 D-8 F
R1020 E-9 F
R1021 D-8 F
R1022 D-8 F
R1023 D-8 F
R1030 D-8 F
R1031 D-8 F
R1032 D-8 F
R1040 E-7 F
R1041 E-8 F
R1042 E-8 F
R1043 E-8 F
R1050 D-9 F
R1051 D-9 F
R1052 D-9 F
R1053 D-9 F
R1054 F-2 C
R1056 F-2 C
R1061 D-9 F
R1062 D-9 F
R1063 D-9 F
R1070 E-9 F
R1071 E-9 F
R1072 E-9 F
R1073 E-2 C
R1074 E-2 C
R1075 E-2 C
R1101 E-4 C
R1102 E-5 C
R1103 E-5 C
R1104 E-5 C
R1105 E-4 C
R1106 E-8 F
R1210 E-7 F
R1211 E-7 F
R1212 E-7 F
R2002 B-7 F
R2003 D-5 C
R2006 E-7 F
R2007 D-7 F
R2012 C-7 F
R2013 C-7 F
R2014 D-7 F
R2017 D-5 C
R3016 E-10 F
R3017 D-3 C
R3018 D-2 C
R3019 D-2 C
R3021 E-2 C
R3030 E-2 C
R3031 E-2 C
R3040 D-2 C
R3041 D-2 C
R3042 D-2 C
R3043 D-2 C
R3051 E-10 F
R3052 E-2 C
R3053 E-2 C
R3061 E-2 C
R3062 E-2 C
R3063 E-2 C
R3071 E-2 C
R4101 E-3 C
R5001 C-8 F
R5002 B-7 F
R5003 B-7 F
R5005 B-8 F
R5006 B-7 F
R5007 B-8 F
R6001 C-9 F
R6008 B-9 F
R6009 B-9 F
R6010 C-3 C
R6011 C-10 F
R6018 B-9 F
R6019 B-8 F
R6020 B-9 F
R6021 C-9 F
R6025 C-9 F
R6026 C-9 F
R6027 C-9 F
R6028 B-9 F
R6029 D-9 F
R6030 C-9 F
R6032 B-9 F
R6033 C-10 F
R6035 C-9 F
R6036 C-9 F
R6037 C-3 C
R6038 C-8 F
R6039 C-8 F
R6040 D-8 F
R6041 D-8 F
R6042 D-8 F
R6043 D-8 F
R6044 E-3 C
R6045 C-9 F
R6046 B-3 C
R6049 C-9 F
R6050 B-3 C
R6060 C-9 F
R7006 B-8 F
R7007 C-4 C
R7008 C-9 F
R7009 B-4 C
R7010 B-5 C
R7011 C-9 F
R7012 C-4 C
R7013 B-4 C
R7014 B-8 F
R7015 B-4 C
R7016 C-8 F
R7017 C-8 F
R7018 C-3 C
R7019 C-4 C
R7023 C-8 F
R7024 C-3 C
R7131 C-3 C
R7132 C-2 C
R7133 C-3 C
R7134 B-3 C
R7135 B-3 C
R7136 C-3 C
R9001 E-7 F
R9014 C-3 C
R9015 B-3 C
R9016 B-3 C
R9017 E-5 C
R9026 E-5 C
R9101 C-7 F
R9102 C-7 F
R9103 C-7 F
R9104 B-7 F
R9105 C-8 F
R9106 B-7 F
R9107 B-7 F
R9108 C-8 F
R9109 C-8 F
R9111 C-8 F
R9112 B-7 F
R9113 C-8 F
R9114 C-7 F
R9115 C-8 F
R9116 C-7 F
R9117 C-7 F
RX6001 B-8 F
RX9001 E-5 C
Varistor
VA9001 C-4 C
VA9002 C-3 C
VA9003 C-4 C
VA9004 C-3 C
VA9005 C-4 C
VA9006 C-3 C
VA9007 C-4 C
VA9008 C-3 C
VA9009 C-4 C
VA9010 C-3 C
VA9011 B-4 C
VA9012 C-4 C
VA9013 B-4 C
VA9014 B-3 C
VA9016 B-3 C
VA9017 B-4 C
VA9018 B-3 C
VA9019 E-5 C
Backup Battery
ZB9101 E-10 F
Ground Terminal
G1001 F-9 F
G1002 F-4 C
G1003 F-8 F
G1004 F-4 C
G1020 E-8 F
G2001 B-7 F
G3001 F-10 F
G9001 E-7 F
Switch
S9501 B-4 C
S9502 C-5 C
S9503 B-5 C
S9504 D-5 C
S9505 C-5 C
S9506 C-4 C
S9507 C-5 C
S9508 E-4 C
Main P.C.B.
