DMC-FS5P/PC/PL/PR/EB/EE/EF/EG/E/GC/GK/GN/GT/GJ

Ref.No. Part No. Part Name & Description Pcs Remarks Ref.No. Part No. Part Name & Description Pcs Remarks

C5004 ECJ0EB1A473K C.CAPACITOR CH 10V 0.047U 1

------ P.C.B. LIST ------ C5005 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

## VEP56057A MAIN P.C.B. 1 (RTL) E.S.D. C5006 ECJ0EB1A473K C.CAPACITOR CH 10V 0.047U 1

C5007 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

C5009 F1H0J106A009 C.CAPACITOR CH 6.3V 10U 1

C5010 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C5011 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

C5012 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

C6001 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

--- INDIVIDUAL PARTS --- C6002 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C6012 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

C6015 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

C6016 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

C6021 ECJ0EC1H090D C.CAPACITOR CH 50V 9P 1

--- ELEC. COMPONENTS --- C6022 ECJ0EC1H090D C.CAPACITOR CH 50V 9P 1

## VEP56057A MAIN P.C.B. (RTL) E.S.D. C6101 F1H0J106A009 C.CAPACITOR CH 6.3V 10U 1

C6102 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

C1001 F1H0J106A009 C.CAPACITOR CH 6.3V 10U 1 C6103 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

C1002 F1H0J106A009 C.CAPACITOR CH 6.3V 10U 1 C6106 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

C1003 ECJ1VB1A334K C.CAPACITOR CH 10V 0.33U 1 C6107 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

C1004 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1 C6108 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

C1005 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1 C6109 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C1006 F1H0J106A009 C.CAPACITOR CH 6.3V 10U 1 C6111 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

C1007 ECJ1VB0J225K C.CAPACITOR CH 6.3V 2.2U 1 C6113 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C1008 ECJ1VB0J225K C.CAPACITOR CH 6.3V 2.2U 1 C6115 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C1010 F1H0J106A009 C.CAPACITOR CH 6.3V 10U 1 C6117 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C1020 F1J0J226A014 C.CAPACITOR CH 6.3V 22U 1 C6118 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C1030 F1H0J106A009 C.CAPACITOR CH 6.3V 10U 1 C6119 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C1040 F1J0J226A014 C.CAPACITOR CH 6.3V 22U 1 C6120 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C1050 F1J1A106A023 C.CAPACITOR CH 10V 10U 1 C6121 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C1051 ECUM1E562KBQ C.CAPACITOR CH 25V 5600P 1 C6123 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C1054 ECJ2FB1E475M C.CAPACITOR CH 25V 4.7U 1 C6125 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C1056 ECJ1XB1C104K C.CAPACITOR CH 16V 0.1U 1 C6128 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C1060 F1J1C106A059 C.CAPACITOR CH 16V 10U 1 C6130 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C1070 F1J1C106A059 C.CAPACITOR CH 16V 10U 1 C6131 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C1211 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C6132 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C2001 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C6133 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C2002 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C6134 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C2003 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C6156 F1G1H1020008 C.CAPACITOR CH 50V 1000P 1

C2004 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C6157 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1

C3001 F3E0J476A014 E.CAPACITOR CH 6.3V 47U 1 C6158 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1

C3002 F3E0J476A014 E.CAPACITOR CH 6.3V 47U 1 C6160 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1

C3003 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1 C6161 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1

C3004 F1H0J106A009 C.CAPACITOR CH 6.3V 10U 1 C6162 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1

C3005 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1 C6163 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1

C3008 F1H0J106A009 C.CAPACITOR CH 6.3V 10U 1 C6164 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1

C3009 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1 C6165 F1H0J475A010 C.CAPACITOR CH 6.3V 4.7U 1

C3011 ECJ1VB1C105K C.CAPACITOR CH 16V 1U 1 C6166 F1H0J475A010 C.CAPACITOR CH 6.3V 4.7U 1

C3012 F1J1A475A034 C.CAPACITOR CH 10V 4.7U 1 C7001 F1H0J106A009 C.CAPACITOR CH 6.3V 10U 1

C3013 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1 C7002 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1

C3014 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1 C7003 ECJ0EB1C103K C.CAPACITOR CH 16V 0.01U 1

C3015 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C7004 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

C3016 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C7005 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

C3023 F1H0J106A009 C.CAPACITOR CH 6.3V 10U 1 C7013 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1

C3024 ECJ1VB0J105K C.CAPACITOR CH 6.3V 1U 1 C7018 ECJ0EB1E222K C.CAPACITOR CH 25V 2200P 1

C3025 ECJ1VB1H104K C.CAPACITOR CH 50V 0.1U 1 C7019 ECJ0EB1E222K C.CAPACITOR CH 25V 2200P 1

C3026 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1 C7022 F1H0J106A009 C.CAPACITOR CH 6.3V 10U 1

C3030 F1J1A475A034 C.CAPACITOR CH 10V 4.7U 1 C7023 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C3031 ECJ1VB1C105K C.CAPACITOR CH 16V 1U 1 C7024 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C3032 ECJ1VB1C105K C.CAPACITOR CH 16V 1U 1 C7101 F1H0J106A009 C.CAPACITOR CH 6.3V 10U 1

C3036 F1J1C225A144 C.CAPACITOR CH 16V 2.2U 1 C7102 ECJ0EB1C153K C.CAPACITOR CH 16V 0.015U 1

C4102 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1 C7103 ECJ0EB1C153K C.CAPACITOR CH 16V 0.015U 1

C4103 ECJ1VB1C105K C.CAPACITOR CH 16V 1U 1 C7106 ECJ0EB1A473K C.CAPACITOR CH 10V 0.047U 1

C4104 ECJ1VB1C105K C.CAPACITOR CH 16V 1U 1 C7107 ECJ0EB1A473K C.CAPACITOR CH 10V 0.047U 1

C4105 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1 C7108 ECJ0EB1E472K C.CAPACITOR CH 25V 4700P 1

C4106 F1J0J1060009 C.CAPACITOR CH 6.3V 10U 1 C7109 ECJ0EB1E472K C.CAPACITOR CH 25V 4700P 1

C4107 F1J0J1060009 C.CAPACITOR CH 6.3V 10U 1 C7110 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C4108 F1J0J226A014 C.CAPACITOR CH 6.3V 22U 1 C7111 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C4109 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1 C7112 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C4110 ECJ1VB1C105K C.CAPACITOR CH 16V 1U 1 C9101 F1G1H1020008 C.CAPACITOR CH 50V 1000P 1

C4111 ECJ1VB1C105K C.CAPACITOR CH 16V 1U 1 C9102 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

C4112 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1 C9103 ECJ0EC1H120J C.CAPACITOR CH 50V 12P 1

C4113 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1 C9104 ECJ0EC1H100D C.CAPACITOR CH 50V 10P 1

C4114 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1 C9105 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

C4115 ECJ1VB1A105K C.CAPACITOR CH 10V 1U 1 C9106 F1G0J1050007 C.CAPACITOR CH 6.3V 1U 1

C5001 F1G1H1020008 C.CAPACITOR CH 50V 1000P 1 C9108 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1

C5002 F1G1A1040006 C.CAPACITOR CH 10V 0.1U 1 C9109 F1H0J475A010 C.CAPACITOR CH 6.3V 4.7U 1

S-32
