VQT1V73
10
Before Use
Names of the Components
1 Flash (P39)
2 Lens (P91)
3 Self-timer indicator (P43)
AF assist lamp (P66)
4 LCD monitor (P38, 89)
5 Status indicator (P15, 23, 28)
6 [MENU/SET] button (P18)
7 [DISPLAY] button (P38)
8 [Q.MENU] (P21)/Delete (P36) button
9 [MODE] button (P27)
10 [REC]/[PLAYBACK] selector switch
(P19)
11 Cursor buttons
A: 3/Exposure compensation (P44)/
Auto bracket (P45)
B: 4/Macro mode (P42)
C: 2/Self-timer button (P43)
D: 1/Flash setting button (P39)
In these operating instructions, the cursor buttons are described as shown in the
figure below or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
