Panasonic LUMIX DMC-FS6 User Manual

VQT1V73
84
Connecting to other equipment
Printing the Pictures
If you connect the camera to a printer supporting PictBridge, you can select the pictures to
be printed out and instruct that printing be started on the camera’s LCD monitor.
Preparations:
Turn on the camera and the printer.
Remove the card before printing the pictures in the built-in memory.
Perform the print quality and other settings at the printer before printing the pictures.
A USB connection cable (supplied)
• Check the directions of the connectors, and plug them straight in or unplug them straight out.
(Otherwise the connectors may be bent out of shape which will cause trouble.)
B Align the marks, and insert.
•
Use a battery with a sufficient battery power or the AC adaptor (DMW-AC5PP; optional) and DC
coupler (DMW-DCC4; optional). If the remaining battery power becomes low while the camera
and the printer are connected, the status indicator blinks and the alarm beeps. If this happens
during printing, stop printing at once. If not printing, disconnect the USB connection cable.
Connect the camera to a printer via the USB connection cable A (supplied).
• When the camera is connected to the printer, the cable disconnect prohibit icon [å]
appears. Do not disconnect the USB cable while [å] is displayed.
Note
• Since the camera may be scratched, it is recommended that you place it on top of a soft cloth
before connecting to a printer.
• Do not use any other USB connection cables except the supplied one.
Use of cables other than the supplied USB connection cable may cause malfunction.
•
Turn the camera off before connecting or disconnecting the AC adaptor (DMW-AC5PP; optional).
• Before inserting or removing a card, turn the camera off, and disconnect the USB connection cable.
• You cannot switch between the built-in memory and the card while the camera is connected to
the printer. Disconnect the USB connection cable, insert (or remove) the card and then connect
the USB connection cable to the printer again.
Press 3/4 to select [PictBridge(PTP)], and then
press [MENU/SET].
DIGITAL
AV OUT
USB MODE
SELECT
SET
PLEASE SELECT
THE USB MODE
PictBridge(PTP)
PC
DMC-FS7&FS6PPC-VQT1V73_eng.book 84 ページ ２００８年１２月１日 月曜日 午後５時１０分

Panasonic LUMIX DMC-FS6 Specifications

General

Megapixel	8.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.5 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	3264 x 2448 pixels
Combined zoom	16 x
Focal length range	5.5 - 22 mm
Lens structure (elements/groups)	6/5
Interface	USB 2.0
Digital SLR	No
Camera shutter speed	8 - 1/2000 s
Focal length (35mm film equivalent)	33 - 132 mm
Focus adjustment	Auto
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Multi Point Auto Focus
Auto Mode focusing range (wide)	0.05 - ∞ m
Flash modes	auto, Flash off, Red-eye reduction
Flash range (tele)	0.5 - 3 m
Flash range (wide)	0.3 - 6.3 m
Internal memory	50 MB
Compatible memory cards	mmc, sd, sdhc
Motion JPEG frame rate	30 fps
Video formats supported	M-JPEG
Maximum video resolution	848 x 480 pixels
Display diagonal	2.5 \
Display resolution (numeric)	230000 pixels
I/O ports	A/V
USB version	2.0
Scene modes	Close-up (macro), Night landscape, Night portrait, Portrait
Image editing	resizing, trimming
Photo effects	Sepia, Vivid
White balance	auto, Cloudy, custom modes, daylight, Fluorescent, Shade
Camera playback	movie, single image, slide show, thumbnails
Self-timer delay	2 s
Product color	Black
Battery capacity	940 mAh
Battery life (CIPA standard)	400 shots
Number of batteries supported	1
Bundled software	PHOTOfunSTUDIO v3.0/ArcSoft QuickTime

Weight and Dimensions

Depth	21.2 mm
Width	97 mm
Height	54.4 mm
Weight	137 g
