VQT1V73
92
Others
The battery is a rechargeable lithium ion battery. Its ability to generate power comes
from the chemical reaction that takes place inside it. This reaction is susceptible to
the surrounding temperature and humidity. If the temperature is too high or too low,
the operating time of the battery will become shorter.
Always remove the battery after use.
Store the removed battery in the battery case (supplied).
If you drop the battery accidentally, check to see if the body
of the battery and the terminals are damaged.
Inserting a damaged battery in the camera will damage the camera.
Bring charged spare batteries when going out.
Be aware that the operating time of the battery becomes shorter in low temperature conditions
such as at a ski resort.
When you travel, do not forget to bring the battery charger (supplied) so that you can charge
the battery in the country that you are traveling in.
Dispose of unusable battery.
The battery has a limited life.
Do not throw the battery into fire because it may cause an explosion.
The unusable battery should be discarded in accordance with battery recycling laws. Call the
RBRC hotline at 1-800-822-8837 for information.
Do not allow battery terminals to come into contact with metal objects (such as
necklaces, hairpins etc.).
This can cause short circuiting or heat generation and you may be badly burned if you touch a
battery.
If you use the battery charger near a radio, the radio reception may be disturbed.
Keep the charger 1 m (3.28 feet) or more away from radios.
The charger may generate whirring sounds when it is being used. This is not a malfunction.
After use, be sure to disconnect the power supply device from the electrical outlet. (A very
small amount of current is consumed if it is left connected.)
Keep the terminals of the charger and battery clean.
Do not leave the card where the temperature is high, where electromagnetic waves
or static electricity are easily generated or exposed to direct sunlight.
Do not bend or drop the card.
The card may be damaged or the recorded content may be damaged or deleted.
Put the card in the card case or the storage bag after use and when storing or carrying the
card.
Do not allow dirt, dust or water to get into the terminals on the back of the card and do not touch
the terminals with your fingers.
Notice for when transferring to another party, or disposing of the memory card
“Format” or “delete” using the camera or a PC will only modify the file management information,
and it will not erase the data in the memory card completely.
It is recommended to physically destroy the memory card or use the commercially available
computer data deletion software to completely erase the data in the memory card before
transferring to another party or disposing.
Management of data in the memory card is the responsibility of the user.
Battery
Charger
Card
DMC-FS7&FS6PPC-VQT1V73_eng.book 92 ペー 008年12月1日 月曜日 午後5時10分

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic LUMIX DMC-FS6 and is the answer not in the manual?

Panasonic LUMIX DMC-FS6 Specifications

General IconGeneral
Megapixel8.1 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Image sensor size1/2.5 \
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution3264 x 2448 pixels
Combined zoom16 x
Focal length range5.5 - 22 mm
Lens structure (elements/groups)6/5
InterfaceUSB 2.0
Digital SLRNo
Camera shutter speed8 - 1/2000 s
Focal length (35mm film equivalent)33 - 132 mm
Focus adjustmentAuto
Normal focusing range0.5 - ∞ m
Auto focusing (AF) modesMulti Point Auto Focus
Auto Mode focusing range (wide)0.05 - ∞ m
Flash modesauto, Flash off, Red-eye reduction
Flash range (tele)0.5 - 3 m
Flash range (wide)0.3 - 6.3 m
Internal memory50 MB
Compatible memory cardsmmc, sd, sdhc
Motion JPEG frame rate30 fps
Video formats supportedM-JPEG
Maximum video resolution848 x 480 pixels
Display diagonal2.5 \
Display resolution (numeric)230000 pixels
I/O portsA/V
USB version2.0
Scene modesClose-up (macro), Night landscape, Night portrait, Portrait
Image editingresizing, trimming
Photo effectsSepia, Vivid
White balanceauto, Cloudy, custom modes, daylight, Fluorescent, Shade
Camera playbackmovie, single image, slide show, thumbnails
Self-timer delay2 s
Product colorBlack
Battery capacity940 mAh
Battery life (CIPA standard)400 shots
Number of batteries supported1
Bundled softwarePHOTOfunSTUDIO v3.0/ArcSoft QuickTime
Weight and Dimensions IconWeight and Dimensions
Depth21.2 mm
Width97 mm
Height54.4 mm
Weight137 g
