12 Camera ON/OFF switch (P18)
13 Zoom lever (P34)
14 Speaker (P90)
15 Microphone (P61, 76, 98)
16 Shutter button (P29, 61)
17 Strap eyelet
•
Be sure to attach the strap when using
the camera to ensure that you will not
drop it.
18 Lens barrel
19 [COMPONENT OUT] socket (P107)
20 [AV OUT/DIGITAL] socket (P100, 102,
106)
21 [DC IN] socket (P100, 102)
•
Always use a genuine Panasonic AC adaptor (DMW-AC5PP; optional).
• This camera cannot charge the battery even when the AC adaptor (DMW-AC5PP;
optional) is connected to it.
22 Tripod receptacle
•
When you use a tripod, make sure the
tripod is stable when the camera is
attached to it.
23 Card/Battery door (P16)
24 Release lever (P16)
12
14
13
15 16
2
1
1
8
2
0
21
1
9
1
7
22 23
24
