13
(ENG) VQT4G94
Changing the Lens
• Check that the camera is turned off.
Align the lens fitting marks A (red marks) and
then rotate the lens in the direction of the arrow
until it clicks.
• Do not press the lens release button B when you attach a
lens.
While pressing on the lens release button B,
rotate the lens toward the arrow until it stops and
then remove.
Attaching the lens
Preparations: Remove the lens rear cap from the lens, and the body cap from the
camera.
Detaching the lens
Preparations: Attach the lens cap.
DMC-G5X&G5K&G5PP-VQT4G94_eng.book 13 ページ ２０１２年６月２２日 金曜日 午前８時２４分
