Panasonic Lumix DMC-G5 Basic Owner's Manual

VQT4G94 (ENG)
36
∫ [Custom] Menu
Operation of the unit, such as displaying of the screen and button operations, can be set
up according to your preferences. Also, it is possible to register the modified settings.
[Flkr Decrease]
The shutter speed can be fixed to reduce the flicker or striping
in the motion picture.
[Cust.Set Mem.] Registers the current camera settings as custom set.
[AF/AE LOCK / Fn1]
Assigns AF/AE lock or Fn1 (function button) to the [AF/AE
LOCK]/[Fn1] button.
[LVF/LCD / Fn3]
Assign the LVF/LCD switching function or Fn3 (function button)
to the [LVF/LCD]/[Fn3] button.
[Fn Button Set]
You can assign various recording and other functions to the
function button.
[Function Lever] You can set the function to assign to the function lever.
[Q.MENU] Switch the setting method of Quick Menu.
[Histogram]
This allows you to set either to display or not display the
histogram.
[Guide Line]
This will set the pattern of guide lines displayed when taking a
picture.
[Auto Review]
Set the length of time that the picture is displayed after taking
the still picture.
[Highlight]
When the Auto Review function is activated or when playing
back, white saturated areas appear blinking in black and white.
[Expo.Meter]
Set whether or not to display the exposure meter.
[AF/AE Lock]
Sets the fixed content for focusing and exposure when the AF/
AE lock is on.
[AF/AE Lock Hold]
This will set the operation of [AF/AE LOCK] button when taking
a picture with fixed focus or exposure.
[Quick AF]
Speeds up the focusing that takes place when you press the
shutter button.
[Eye Sensor AF]
The camera automatically adjusts the focus when the eye
sensor is active.
[Direct Focus Area]
Moves the AF area or MF assist using the cursor button when
recording.
[Focus Priority]
It will set so no picture can be taken when it is out of focus.
[Shutter AF]
Set whether or not the focus is adjusted automatically when the
shutter button is pressed halfway.
DMC-G5X&G5K&G5PP-VQT4G94_eng.book 36 ページ ２０１２年６月２２日 金曜日 午前８時２４分

Panasonic Lumix DMC-G5 Specifications

General

Megapixel	16.05 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	18.31 MP
Image sensor size	- \
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	- pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	-
Digital zoom	4 x
Optical zoom	- x
Focal length range	14 - 42 mm
Maximum aperture number	22
Number of diaphragm blades	7
Lens structure (elements/groups)	12/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.3 m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	160, 200, 400, 1600, 3200, 6400, 12800
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	160
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	0.00625 s
Power source type	Battery
Audio system	stereo
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Magnification	1.4 x
USB version	2.0
HDMI connector type	Mini
Product color	Black
Scene modes	Backlight, Children, Cuisine, Night landscape, Pet, Portrait, Sports, Sunset, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Art, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Flash, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
Image quality adjustment	Brightness, Contrast, Saturation
On Screen Display (OSD) languages	ENG, ESP, POR
Cables included	USB
Bluetooth	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	70.8 mm
Width	119.9 mm
Height	83.2 mm
Weight	346 g
Weight (including battery)	396 g
