Panasonic Lumix DMC-G5 User Manual

- 16 -
Before Use
About the Lens
∫ Micro Four Thirds™ mount specification lens
This unit can use the dedicated lenses compatible with the
Micro Four Thirds System lens mount specification (Micro
Four Thirds mount).
∫ Four Thirds™ mount specification lens
Lens with the Four Thirds mount specification can be used by
using the mount adaptor (DMW-MA1: optional).
∫ Leica mount specification lens
•
When you use the M mount adaptor or R mount adaptor (DMW-MA2M, DMW-MA3R: optional), you
can use Leica M Mount or Leica R Mount interchangeable lenses.
–For certain lenses, the actual distance at which the subject is in focus may differ slightly from the
rated distance.
–When using a Leica lens mount adaptor, set [Shoot w/o Lens] (P172) to [ON].
There are functions that cannot be used, or the operation may be different depending on the
lens used.
Auto Focus
¢
/Auto aperture setting
¢
/[Eye Sensor AF] (P35)/Defocus control function (P48)/
[Stabilizer] (P78)/Touch zoom (P83)/[Shading Comp.] (P155)/[Quick AF] (P166)/[Power Zoom
Lens] (P169)
¢ The interchangeable lens (H-PS14042, H-FS014042 or H-FS45150) is compatible with the Auto
Focus and automatic Aperture operation during the recording of motion pictures. With the
interchangeable lens (H-PS14042), when using the power zoom (electrically operated zoom); you
can record motion pictures even more smoothly and quietly thanks to the powerful high AF
following performance and silence design.
For details on the lens used, refer to the website.
Note
•
The available flash range etc. differs depending on the aperture value of the lens you are using.
• The focal length noted on the lens in use is equivalent to double when converted to the 35 mm film
camera. (It will be equivalent to 100 mm lens when a 50 mm lens is used.)
Refer to the website for details about the 3D interchangeable lens.
About the lens and functions
Refer to catalogs/Web pages for most current information regarding compatible lenses.
http://panasonic.jp/support/global/cs/dsc/
(This Site is English only.)

Panasonic Lumix DMC-G5 Specifications

General

Megapixel	16.05 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	18.31 MP
Image sensor size	- \
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	- pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	-
Digital zoom	4 x
Optical zoom	- x
Focal length range	14 - 42 mm
Maximum aperture number	22
Number of diaphragm blades	7
Lens structure (elements/groups)	12/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.3 m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	160, 200, 400, 1600, 3200, 6400, 12800
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	160
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	0.00625 s
Power source type	Battery
Audio system	stereo
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Magnification	1.4 x
USB version	2.0
HDMI connector type	Mini
Product color	Black
Scene modes	Backlight, Children, Cuisine, Night landscape, Pet, Portrait, Sports, Sunset, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Art, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Flash, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
Image quality adjustment	Brightness, Contrast, Saturation
On Screen Display (OSD) languages	ENG, ESP, POR
Cables included	USB
Bluetooth	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	70.8 mm
Width	119.9 mm
Height	83.2 mm
Weight	346 g
Weight (including battery)	396 g
