Panasonic Lumix DMC-G5 User Manual

- 208 -
Others
The MC protector is a transparent filter which affects neither the colors nor the amount of light,
so it can always be used to protect the camera’s lens.
The ND filter reduces the amount of light to approximately 1/8th (equal to adjusting the aperture
value 3 increments) without affecting the color balance.
PL filter will suppress the reflected light from a metal or non spherical surfaces (flat non-metallic
surfaces, water vapour or invisible particles in the air), making it possible to take a picture with
enhanced contrast.
Note
•
When using the interchangeable lens (H-PS14042), turn this unit off and ensure the lens barrel is
retracted before attaching or removing a filter.
• Do not attach multiple filters at the same time.
• You can attach the lens cap or the lens hood when the filter is attached.
• Refer to the instructions for each filter for details.
If you use the remote shutter (DMW-RSL1: optional), you can avoid jitter (camera shake) when
using a tripod and you can keep the shutter pressed fully when taking pictures with [B] (Bulb) or
Burst Mode. The remote shutter works similar to the shutter button on the camera.
Note
•
Always use a genuine Panasonic remote shutter (DMW-RSL1: optional).
• You cannot operate the camera with the remote shutter in the following cases.
– When the Sleep Mode is canceled
– When starting/ending the recording of motion pictures
• Read the operating instructions of the remote shutter for details.
By connecting the AC adaptor (optional), and then plugging them into an electrical socket, you
can connect this unit to a PC or printer and use without worrying about the capacity of the
battery. To use the AC adaptor, a DC coupler (optional) is required.
Note
•
Always use a genuine Panasonic AC adaptor (optional).
• When using an AC adaptor, use the AC cable supplied with the AC adaptor.
• Also read the operating instructions for the AC adaptor and DC coupler.
Filters (optional)
Remote Shutter (optional)
AC adaptor (optional)/DC coupler (optional)

Panasonic Lumix DMC-G5 Specifications

General

Megapixel	16.05 MP
Camera type	MILC
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	18.31 MP
Image sensor size	- \
Supported aspect ratios	1:1, 3:2, 4:3, 16:9
Maximum image resolution	- pixels
Image sensor size (W x H)	17.3 x 13 mm
Image stabilizer location	Body
Still image resolution(s)	-
Digital zoom	4 x
Optical zoom	- x
Focal length range	14 - 42 mm
Maximum aperture number	22
Number of diaphragm blades	7
Lens structure (elements/groups)	12/9
Maximum focal length (35mm film equiv)	84 mm
Minimum focal length (35mm film equiv)	28 mm
Auto focusing (AF) modes	Continuous Auto Focus, Flexible Spot Auto Focus, Single Auto Focus, Tracking Auto Focus
Closest focusing distance	0.3 m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	160, 200, 400, 1600, 3200, 6400, 12800
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	12800
ISO sensitivity (min)	160
Light exposure control	Program AE
Light exposure correction	± 5EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash sync-speed	0.00625 s
Power source type	Battery
Audio system	stereo
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display aspect ratio	3:2
Magnification	1.4 x
USB version	2.0
HDMI connector type	Mini
Product color	Black
Scene modes	Backlight, Children, Cuisine, Night landscape, Pet, Portrait, Sports, Sunset, Landscape (scenery)
Image editing	Crop, Resizing, Rotating
Photo effects	Art, Neutral, Sepia, Vivid
White balance	Auto, Cloudy, Flash, Incandescent, Shade
Camera playback	Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
Image quality adjustment	Brightness, Contrast, Saturation
On Screen Display (OSD) languages	ENG, ESP, POR
Cables included	USB
Bluetooth	No
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	70.8 mm
Width	119.9 mm
Height	83.2 mm
Weight	346 g
Weight (including battery)	396 g
