Panasonic Lumix DMC-LS85 - Names of the Components

Before Use
- 9 -
Names of the Components
AV OUT
/DIGITAL
10
9
8 7
4
6
5
3
2
1
22

11
19
20
21
17
16
12
18
13
14
15
1 [
4
] button (P30)
2 Zoom lever (P37)
3 Shutter button (P30)
4 Microphone (P64)
5 Flash (P46)
6 Self-timer indicator (P52)
AF assist lamp (P81)
7 Lens part
8 Lens barrel
9 [AV OUT/DIGITAL] socket (P99,
102, 108)
10 Speaker (P25, 86)
11 LCD monitor (P44, 128)
12 Recording/playback switch
(P20)
13 [MENU/SET] button (P20)
14 Camera ON/OFF
switch (P18)
