Panasonic Lumix DMC-LX5 Operating Instructions

Connecting to other equipment
- 188 -
Connect the camera to a PC via the USB connection cable A
(supplied).
• Do not use any other USB connection cables except the supplied one.
Use of cables other than the supplied USB connection cable may cause malfunction.
Using a drag-and-drop operation, move the pictures you want to
acquire or the folder storing those pictures to any different folder on
the PC.
∫ Disconnecting the USB connection cable safely
•
Proceed with the hardware removal using “Safely Remove Hardware” on the task tray of the
PC. If the icon is not displayed, check that [ACCESS] is not displayed on the LCD monitor of
the digital camera before removing the hardware.
Note
•
This unit cannot stand upright when the AC adaptor is connected. When placing it on a surface
and operating it, we recommend placing it on a soft cloth.
• Turn the camera off before connecting or disconnecting the AC adaptor (optional).
• Before inserting or removing a card, turn the camera off and disconnect the USB connection
cable. Otherwise, data may be destroyed.
Press 3/4 to select [PC], and then press [MENU/
SET].
• If [USB MODE] (P37) is set to [PC] in the [SETUP] menu in
advance, the camera will be automatically connected to the PC
without displaying the [USB MODE] selection screen. Since
there is no need to set this each time you connect to the PC, it
is convenient.
• When the camera has been connected to the PC with
[USB MODE] set to [PictBridge(PTP)], a message may appear
on the PC’s screen. Select [Cancel] to close the screen, and
disconnect the camera from the PC. Then set [USB MODE] to
[PC] again.
Double-click on [Removable Disk] in [My Computer].
• When using a Macintosh, the drive is displayed on the desktop. (“LUMIX”, “NO_NAME”
or “Untitled” is displayed.)
Double-click [DCIM] folder.
USB MODE
PLEASE SELECT
THE USB MODE
SELECT
SET
PictBridge(PTP)
PC

Panasonic Lumix DMC-LX5 Specifications

General

Megapixel	10.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	11.3 MP
Image sensor size	- \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	3648 x 2736 pixels
Still image resolution(s)	480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1600 x 1200, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2304 x 2304, 2560 x 1920, 2736 x 2736, 3072 x 2304, 3328 x 1872, 3648 x 2736, 3968 x 2232
Digital zoom	4 x
Optical zoom	3.8 x
Extra/Smart zoom	6.7 x
Focal length range	5.1 - 19.2 mm
Number of diaphragm blades	5
Number of aspheric elements	3
Lens structure (elements/groups)	10/9
Aperture range (F-F)	2 - 3.3
Camera shutter speed	60 - 1/4000 s
Focal length (35mm film equivalent)	24 - 90 mm
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Selective Auto Focus
Macro focusing range (tele)	0.3 - ∞ m
Macro focusing range (wide)	1 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Camera shutter interval	0.5 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 4.4 m
Flash range (wide)	0.8 - 7.2 m
Scene modes	Beach, Candlelight, Children, Close-up (macro), Cuisine, Fireworks, Night landscape, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	-
White balance	Auto, Cloudy, Daylight, Flash, Shade
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, Exif 2.3
Playback zoom (max)	16 x
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Video resolutions	320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, M-JPEG
Maximum video resolution	1280 x 720 pixels
Analog signal format system	NTSC, PAL
Internal memory	40 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Black
Battery voltage	3.6 V
Battery capacity	1250 mAh
Battery life (CIPA standard)	400 shots
Cables included	AC, AV, USB
Bundled software	PHOTOfunSTUDIO 5.0 HD Edition, / SILKYPIX Developer Studio 3.1 SE, / QuickTime / Adobe Reader

Weight and Dimensions

Depth	43 mm
Width	109.7 mm
Height	65.5 mm
Weight	233 g
Weight (including battery)	271 g
