Panasonic Lumix DMC-LX5 Operating Instructions

Others
- 222 -
• Is the [OPT. VIEWFINDER] (P149) set to [ON]?
> Press [DISPLAY] to switch to the LCD monitor.
• Does the picture appear on the External Live Viewfinder (optional)?
> Switch to LCD monitor display by pressing [LVF/LCD] on the External Live Viewfinder
(optional). (P196)
• It is only displayed on the LCD monitor when the camera is connected to a PC or printer.
• This is not a malfunction.
These pixels do not affect the recorded pictures.
• In dark places, noise may appear to maintain the brightness of the LCD monitor. This does not
affect the pictures you are recording.
• This is a characteristic of the drive system of the External Live Viewfinder (optional) of this unit,
and it is not a malfunction. There will be no problem with the recorded image.
• Is the flash closed?
> Open the flash by sliding [‰ OPEN]. (P67)
• Flash Mode is not available when [AUTO BRACKET] (P78), [MULTI FILM] (P126) or [BURST]
(P144) has been set.
• The flash is activated twice when Red-Eye Reduction (P68) has been set.
• Has [FLASH BURST] (P101) in Scene Mode been set?
The picture is not displayed on the LCD monitor.
The picture does not switch between LCD monitor and External Live Viewfinder
when [LVF/LCD] is pressed on the External Live Viewfinder (optional).
Black, red, blue and green dots appear on the LCD monitor.
Noise appears on the LCD monitor.
You see red, green, or blue flashes when you move your eyes in the External
Live Viewfinder (optional), or when the camera is moved rapidly.
Flash
The flash is not activated.
Flash is activated several times.

Panasonic Lumix DMC-LX5 Specifications

General

Megapixel	10.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Total megapixels	11.3 MP
Image sensor size	- \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	3648 x 2736 pixels
Still image resolution(s)	480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1600 x 1200, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2304 x 2304, 2560 x 1920, 2736 x 2736, 3072 x 2304, 3328 x 1872, 3648 x 2736, 3968 x 2232
Digital zoom	4 x
Optical zoom	3.8 x
Extra/Smart zoom	6.7 x
Focal length range	5.1 - 19.2 mm
Number of diaphragm blades	5
Number of aspheric elements	3
Lens structure (elements/groups)	10/9
Aperture range (F-F)	2 - 3.3
Camera shutter speed	60 - 1/4000 s
Focal length (35mm film equivalent)	24 - 90 mm
Normal focusing range	0.5 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Selective Auto Focus
Macro focusing range (tele)	0.3 - ∞ m
Macro focusing range (wide)	1 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, 3200, 6400, 12800, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
Light exposure control	Program AE
Light exposure correction	± 3EV (1/3EV step)
Camera shutter interval	0.5 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	0.3 - 4.4 m
Flash range (wide)	0.8 - 7.2 m
Scene modes	Beach, Candlelight, Children, Close-up (macro), Cuisine, Fireworks, Night landscape, Night portrait, Panorama, Party (indoor), Portrait, Self-portrait, Snow, Sports, Sunset, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	-
White balance	Auto, Cloudy, Daylight, Flash, Shade
Shooting modes	Aperture priority, Auto, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF 2.0, Exif 2.3
Playback zoom (max)	16 x
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Video resolutions	320 x 240, 640 x 480, 1280 x 720 pixels
Motion JPEG frame rate	30 fps
Video formats supported	AVCHD, M-JPEG
Maximum video resolution	1280 x 720 pixels
Analog signal format system	NTSC, PAL
Internal memory	40 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Black
Battery voltage	3.6 V
Battery capacity	1250 mAh
Battery life (CIPA standard)	400 shots
Cables included	AC, AV, USB
Bundled software	PHOTOfunSTUDIO 5.0 HD Edition, / SILKYPIX Developer Studio 3.1 SE, / QuickTime / Adobe Reader

Weight and Dimensions

Depth	43 mm
Width	109.7 mm
Height	65.5 mm
Weight	233 g
Weight (including battery)	271 g
