Panasonic Lumix DMC-TZ30 User Manual

- 130 -
Using the GPS function to record the location of a picture
DMC-TZ30 DMC-TZ31
■
Displaying the status and result of positioning
The icons that indicate the status and result of positioning will appear on the LCD
monitor. When positioning is successful, camera will search the place name information
(name of place and landmark) inside its internal database and display it.
Place name
information
• Country/region
• Province/state
• City/borough/county
• Town/village
• Landmark
GPS reception icon
Positioning
executed
successfully
The same number of icons as the number of
the GPS satellites (from which radio signals are
successfully received) stop flashing and light (blue).
If the three bars of the GPS reception icon do not
light and the icon turns off, it means that positioning
was unsuccessful.
Positioning result icons
Icon
Time elapsed after successful positioning
Less than 5 minutes
5 minutes to 1 hour have elapsed.
1 hour to 2 hours have elapsed.
2 hours or more have elapsed.
Positioning failed. No location information/place
name information available.
Even if GPS reception is good, it will take approx. 2 to 3 minutes to
successfully execute positioning in the following cases:
• When positioning is executed for the first time
• When [GPS Setting] is set to [OFF]
• When [Airplane Mode] is set to [ON] and the camera is turned off
• While the battery is removed
Positioning can be executed faster when you download GPS assist data to the
camera using the “GPS Assist Tool”. (→141)

Panasonic Lumix DMC-TZ30 Specifications

General

Megapixel	14.1 MP
Camera type	Compact camera
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	15.3 MP
Image sensor size	1/2.33 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4320 x 3240 pixels
Still image resolution(s)	480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2304 x 2304, 2560 x 1440, 2560 x 1712, 2560 x 1920, 2736 x 2736, 3072 x 1728, 3072 x 2048, 3072 x 2304, 3232 x 3232, 3648 x 2056, 3648 x 2432, 3648 x 2736, 4320 x 2432, 4320 x 2880, 4320 x 3240
Digital zoom	4 x
Optical zoom	20 x
Extra/Smart zoom	42.2 x
Focal length range	4.3 - 86 mm
Maximum aperture number	6.4
Minimum aperture number	3.3
Number of aspheric elements	3
Lens structure (elements/groups)	12/10
Maximum focal length (35mm film equiv)	480 mm
Minimum focal length (35mm film equiv)	24 mm
Focus	TTL
Focus adjustment	Auto
Normal focusing range	0.5 - ∞/2 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.03 - ∞ m
Normal focusing range (tele)	2 - ∞ m
Normal focusing range (wide)	0.5 - ∞ m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 3.3 m
Flash range (wide)	0.6 - 6.4 m
Digital SLR	No
Power source type	Battery
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	AVCHD, M-JPEG, MOV, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio system	Mono
Internal memory	12 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Silver
Scene modes	Children, Night landscape, Night portrait, Panorama, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Shooting modes	Auto, Movie, Program, Scene
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Battery voltage	3.6 V
Battery capacity	895 mAh
Battery life (CIPA standard)	260 shots
Cables included	USB

Weight and Dimensions

Depth	28.2 mm
Width	104.9 mm
Height	58.9 mm
Weight	184 g
Weight (including battery)	206 g
