- 8 -
Before use
About GPS
DMC-TZ30
DMC-TZ31
About the camera’s location name information
Before using the camera, be sure to read “Licence Agreement for Place Name and Map
Data”. (190)
When [GPS Setting] is [ON], the GPS function works even if the camera is turned
OFF.
Electromagnetic waves from the camera can affect instruments and meters. In
airplane cabins (during takeoff and landing) or in other restricted areas, set [GPS
Setting] to [OFF] or set [Airplane Mode] to [ON], and then turn off the camera. (129, 135)
When [GPS Setting] is [ON] and [Airplane Mode] is [OFF], power will drain from the
battery even if the camera is turned OFF.
Recording location information
The names of recording locations and landmarks (such as buildings) are current as of
December 2011. These will not be updated.
Depending on the country or area, limited location name and landmark information
may be available.
Positioning
Positioning will take time in environments where it is difficult to receive the signals
from the GPS satellites. (128)
Even if GPS reception is good, it will take approx. 2 to 3 minutes to
successfully execute positioning under the following conditions: when
positioning is executed for the first time, or when positioning is executed after
the camera is turned off with the [GPS Setting] set to [OFF] or [Airplane Mode]
set to [ON], and then turned on again.
Positioning can be executed faster using GPS assist data. (141)
Because the positions of the GPS satellites are constantly changing, depending on
the recording location and conditions, it may not be possible to position such satellites
accurately, or positioning discrepancy may occur.
When using in another country
The GPS function may not work in China or in the border regions of countries
neighboring China. (Current as of December 2011)
Some countries or regions may regulate the use of GPS or related technology.
Because this camera has a GPS function, before taking it into another country, check
with the embassy or your travel agency whether there are any restrictions on bringing
cameras with a GPS function.

Table of Contents

Other manuals for Panasonic Lumix DMC-TZ30

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-TZ30 and is the answer not in the manual?

Panasonic Lumix DMC-TZ30 Specifications

General IconGeneral
Megapixel14.1 MP
Camera typeCompact camera
Sensor typeLive MOS
Image stabilizerYes
Total megapixels15.3 MP
Image sensor size1/2.33 \
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4320 x 3240 pixels
Still image resolution(s)480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2304 x 2304, 2560 x 1440, 2560 x 1712, 2560 x 1920, 2736 x 2736, 3072 x 1728, 3072 x 2048, 3072 x 2304, 3232 x 3232, 3648 x 2056, 3648 x 2432, 3648 x 2736, 4320 x 2432, 4320 x 2880, 4320 x 3240
Digital zoom4 x
Optical zoom20 x
Extra/Smart zoom42.2 x
Focal length range4.3 - 86 mm
Maximum aperture number6.4
Minimum aperture number3.3
Number of aspheric elements3
Lens structure (elements/groups)12/10
Maximum focal length (35mm film equiv)480 mm
Minimum focal length (35mm film equiv)24 mm
FocusTTL
Focus adjustmentAuto
Normal focusing range0.5 - ∞/2 - ∞ m
Auto focusing (AF) modesContinuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.03 - ∞ m
Normal focusing range (tele)2 - ∞ m
Normal focusing range (wide)0.5 - ∞ m
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, Auto
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)6400
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/2000 s
Slowest camera shutter speed15 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1 - 3.3 m
Flash range (wide)0.6 - 6.4 m
Digital SLRNo
Power source typeBattery
Video resolutions320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supportedAVCHD, M-JPEG, MOV, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Audio systemMono
Internal memory12 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)460000 pixels
USB version2.0
Product colorSilver
Scene modesChildren, Night landscape, Night portrait, Panorama, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editingCrop, Resizing
Photo effectsBlack&White, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Shooting modesAuto, Movie, Program, Scene
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Battery voltage3.6 V
Battery capacity895 mAh
Battery life (CIPA standard)260 shots
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Depth28.2 mm
Width104.9 mm
Height58.9 mm
Weight184 g
Weight (including battery)206 g
