Page #176 background imageLoading...
Page #176 background image
- 176 -
Message displays
Meanings of and required responses to major messages displayed on LCD monitor.
[This memory card cannot be used]
A MultiMediaCard was inserted.
Not compatible with the camera. Use a compatible card.
[Some pictures cannot be deleted] [This picture cannot be deleted]
Non-DCF pictures (42) cannot be deleted.
Save needed data on a computer or other device, and then use [Format] on the camera. (60)
[No additional selections can be made]
The number of pictures that can be deleted at once has been exceeded.
More than 999 pictures have been set as [Favorite].
The number of pictures allowing [Title Edit], [Text Stamp] or [Resize] (multiple settings) at once has
been exceeded.
[Cannot be set on this picture]
[Print Set], [Title Edit], or [Text Stamp] cannot be made for non-DCF pictures (42).
[Please turn camera off and then on again] [System Error]
The lens is not working correctly.
Turn on power again.
(Consult the dealer or your nearest Service Centre if display still remains)
[Some pictures cannot be copied] [Copy could not be completed]
Pictures cannot be copied in following cases.
Picture of same name already exists in built-in memory when copying from card.
File is not of DCF standard (42).
Picture taken or edited on a different device.
[Not enough space on built-in memory] [Not enough memory on the card]
There is no space left on the built-in memory or the card. When you copy pictures from the built-in
memory to the card (batch copy), the pictures are copied until the capacity of the card becomes full.
[Built-In Memory Error] [Format built-in memory?]
Displayed when formatting built-in memory via computer, etc.
Reformat directly using camera. Data will be deleted.
[Memory card error. This card cannot be used in this camera. Format this card?]
The card format cannot be used with this camera.
Save needed data on a computer or other device, and then use [Format] on the camera. (60)
[Insert SD card again] [Try another card]
Access to card has failed.
Insert card again.
Try with a different card.

Table of Contents

Other manuals for Panasonic Lumix DMC-TZ30

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-TZ30 and is the answer not in the manual?

Panasonic Lumix DMC-TZ30 Specifications

General IconGeneral
Megapixel14.1 MP
Camera typeCompact camera
Sensor typeLive MOS
Image stabilizerYes
Total megapixels15.3 MP
Image sensor size1/2.33 \
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4320 x 3240 pixels
Still image resolution(s)480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2304 x 2304, 2560 x 1440, 2560 x 1712, 2560 x 1920, 2736 x 2736, 3072 x 1728, 3072 x 2048, 3072 x 2304, 3232 x 3232, 3648 x 2056, 3648 x 2432, 3648 x 2736, 4320 x 2432, 4320 x 2880, 4320 x 3240
Digital zoom4 x
Optical zoom20 x
Extra/Smart zoom42.2 x
Focal length range4.3 - 86 mm
Maximum aperture number6.4
Minimum aperture number3.3
Number of aspheric elements3
Lens structure (elements/groups)12/10
Maximum focal length (35mm film equiv)480 mm
Minimum focal length (35mm film equiv)24 mm
FocusTTL
Focus adjustmentAuto
Normal focusing range0.5 - ∞/2 - ∞ m
Auto focusing (AF) modesContinuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.03 - ∞ m
Normal focusing range (tele)2 - ∞ m
Normal focusing range (wide)0.5 - ∞ m
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, Auto
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)6400
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/2000 s
Slowest camera shutter speed15 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1 - 3.3 m
Flash range (wide)0.6 - 6.4 m
Digital SLRNo
Power source typeBattery
Video resolutions320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supportedAVCHD, M-JPEG, MOV, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Audio systemMono
Internal memory12 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)460000 pixels
USB version2.0
Product colorSilver
Scene modesChildren, Night landscape, Night portrait, Panorama, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editingCrop, Resizing
Photo effectsBlack&White, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Shooting modesAuto, Movie, Program, Scene
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Battery voltage3.6 V
Battery capacity895 mAh
Battery life (CIPA standard)260 shots
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Depth28.2 mm
Width104.9 mm
Height58.9 mm
Weight184 g
Weight (including battery)206 g
