- 141 -
Reducing the time required for positioning
DMC-TZ30 DMC-TZ31
You can reduce the time required for positioning by copying in advance the predicted
satellite information (GPS assist data) of GPS satellites required for positioning to the
camera.
A computer that can be connected to the Internet is required to download the GPS
assist data.
If the camera’s clock is not set, the GPS assist data cannot be used.
The GPS assist data is valid for 30 days.
The GPS assist data is updated once a day.
The GPS assist data provider service may be changed or discontinued without prior
notice. (The current service is provided as of January 2012.)
About the “GPS Assist Tool”
You can use the “GPS Assist Tool” to download the GPS assist data from the Internet and
update the GPS assist data of the camera.
Operating environment
Supported
OS
Windows
®
XP (32-bit) SP3
Windows Vista
®
(32-bit) SP2
Windows
®
7 (32-bit, 64-bit) and SP1
Mac
®
OS X v10.4, v10.5, v10.6, and v10.7
You do not need to install the software on your computer.
Using the “GPS Assist Tool”
You can operate the “GPS Assist Tool” using the following methods.
Connecting the camera and a computer to execute the
“GPS Assist Tool” stored in the camera .............................................142
Copying the “GPS Assist Tool” to a memory card and use the
card reader/writer (commercially available) to execute the
“GPS Assist Tool” .................................................................................143
If the “GPS Assist Tool” cannot be used, download the GPS assist data from the
support site and copy it to a memory card.
To access the support site, double-click “GPSASIST.HTM”, which is displayed when
the camera is connected to a computer or when the “GPS Assist Tool” is copied to a
memory card.
For detailed procedures, such as downloading the GPS assist data, read the
information displayed on the support site.

Table of Contents

Other manuals for Panasonic Lumix DMC-TZ30

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Panasonic Lumix DMC-TZ30 and is the answer not in the manual?

Panasonic Lumix DMC-TZ30 Specifications

General IconGeneral
Megapixel14.1 MP
Camera typeCompact camera
Sensor typeLive MOS
Image stabilizerYes
Total megapixels15.3 MP
Image sensor size1/2.33 \
Supported aspect ratios3:2, 4:3, 16:9
Maximum image resolution4320 x 3240 pixels
Still image resolution(s)480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2304 x 2304, 2560 x 1440, 2560 x 1712, 2560 x 1920, 2736 x 2736, 3072 x 1728, 3072 x 2048, 3072 x 2304, 3232 x 3232, 3648 x 2056, 3648 x 2432, 3648 x 2736, 4320 x 2432, 4320 x 2880, 4320 x 3240
Digital zoom4 x
Optical zoom20 x
Extra/Smart zoom42.2 x
Focal length range4.3 - 86 mm
Maximum aperture number6.4
Minimum aperture number3.3
Number of aspheric elements3
Lens structure (elements/groups)12/10
Maximum focal length (35mm film equiv)480 mm
Minimum focal length (35mm film equiv)24 mm
FocusTTL
Focus adjustmentAuto
Normal focusing range0.5 - ∞/2 - ∞ m
Auto focusing (AF) modesContinuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)1 - ∞ m
Macro focusing range (wide)0.03 - ∞ m
Normal focusing range (tele)2 - ∞ m
Normal focusing range (wide)0.5 - ∞ m
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 200, 400, 800, 1600, 3200, 6400, Auto
Light exposure modesAperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)6400
ISO sensitivity (min)100
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/2000 s
Slowest camera shutter speed15 s
Flash modesAuto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)1 - 3.3 m
Flash range (wide)0.6 - 6.4 m
Digital SLRNo
Power source typeBattery
Video resolutions320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supportedAVCHD, M-JPEG, MOV, MP4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Audio systemMono
Internal memory12 MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3 \
Display resolution (numeric)460000 pixels
USB version2.0
Product colorSilver
Scene modesChildren, Night landscape, Night portrait, Panorama, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editingCrop, Resizing
Photo effectsBlack&White, Sepia, Vivid
White balanceAuto, Cloudy, Daylight, Incandescent, Shade
Shooting modesAuto, Movie, Program, Scene
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Camera file systemDCF, Exif 2.3
On Screen Display (OSD) languagesDEU, ENG, ESP, FRE, ITA, JPN
Battery voltage3.6 V
Battery capacity895 mAh
Battery life (CIPA standard)260 shots
Cables includedUSB
Weight and Dimensions IconWeight and Dimensions
Depth28.2 mm
Width104.9 mm
Height58.9 mm
Weight184 g
Weight (including battery)206 g
