Panasonic Lumix DMC-TZ30 User Manual

- 144 -
Reducing the time required for positioning
DMC-TZ30 DMC-TZ31
Updating the GPS assist data
Start up the “GPS Assist Tool” on the computer
■
Windows
Double-click [GPSASIST.EXE] stored in the connected camera or memory card
The “GPS Assist Tool” will start up.
• When the “GPS Assist Tool” is copied to the memory card, [GPSASIST.EXE]
is stored in the [AD_LUMIX] folder.
■
Mac
Double-click [GPSASIST.DMG] stored in the connected camera or memory
card
• When the “GPS Assist Tool” is copied to the memory card, [GPSASIST.DMG]
is stored in the [AD_LUMIX] folder.
Double-click [GPSASIST]
The “GPS Assist Tool” will start up.
Operate the “GPS Assist Tool”
Click [Update]
Click [Yes]
Click [OK]
Click [Exit]
• Do not terminate the connection
between the camera/card and computer
until the data is updated.
Terminate the connection between camera/card and computer
• Windows: Execute “Safely Remove Hardware” on the taskbar
• Mac: Open the Finder and click the eject icon that appears on the sidebar
■
Changing the proxy settings
Perform the proxy settings only if the GPS assist data cannot be updated successfully
when the computer is connected to the Internet via proxy.
Click [Settings]
Perform the proxy settings
Windows: Enable [Use proxy server.] and change the settings.
Mac: Change the settings using the network settings screen of the displayed system
environment settings screen.

Panasonic Lumix DMC-TZ30 Specifications

General

Megapixel	14.1 MP
Camera type	Compact camera
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	15.3 MP
Image sensor size	1/2.33 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4320 x 3240 pixels
Still image resolution(s)	480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2304 x 2304, 2560 x 1440, 2560 x 1712, 2560 x 1920, 2736 x 2736, 3072 x 1728, 3072 x 2048, 3072 x 2304, 3232 x 3232, 3648 x 2056, 3648 x 2432, 3648 x 2736, 4320 x 2432, 4320 x 2880, 4320 x 3240
Digital zoom	4 x
Optical zoom	20 x
Extra/Smart zoom	42.2 x
Focal length range	4.3 - 86 mm
Maximum aperture number	6.4
Minimum aperture number	3.3
Number of aspheric elements	3
Lens structure (elements/groups)	12/10
Maximum focal length (35mm film equiv)	480 mm
Minimum focal length (35mm film equiv)	24 mm
Focus	TTL
Focus adjustment	Auto
Normal focusing range	0.5 - ∞/2 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.03 - ∞ m
Normal focusing range (tele)	2 - ∞ m
Normal focusing range (wide)	0.5 - ∞ m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 3.3 m
Flash range (wide)	0.6 - 6.4 m
Digital SLR	No
Power source type	Battery
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	AVCHD, M-JPEG, MOV, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio system	Mono
Internal memory	12 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Silver
Scene modes	Children, Night landscape, Night portrait, Panorama, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Shooting modes	Auto, Movie, Program, Scene
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Battery voltage	3.6 V
Battery capacity	895 mAh
Battery life (CIPA standard)	260 shots
Cables included	USB

Weight and Dimensions

Depth	28.2 mm
Width	104.9 mm
Height	58.9 mm
Weight	184 g
Weight (including battery)	206 g
