Panasonic Lumix DMC-TZ30 User Manual

- 76 -
Taking Pictures with different picture effects [Creative Control] mode
●
A setting that was selected in [Creative Control] mode is retained even after the camera
is turned off.
●
Following [Rec] menu settings will be automatically adjusted and cannot be selected
manually.
[Sensitivity], [White Balance], [i.Exposure], [Min. Shtr Speed], [Color Mode]
●
Notes on the [Miniature Effect] setting
• The recording screen is displayed with a slight delay when compared to usual
recording.
• No audio is recorded for motion pictures.
• Portrait orientation recording does not affect the blurred part. (The left and right edges
will be blurred.)
• When a motion picture is recorded, the finished recording will be approximately 1/8th
of the actual recorded time period. (If you record a motion picture for 8 minutes,
the resulting motion picture recording time will be approximately 1 minute.) The
recordable time displayed on the camera is approx. 8 times longer than actual time
needed for recording. When the recording mode is changed, be sure to check the
recordable time.
• If you stop recording motion pictures too soon, the camera may continue recording
until a certain time. Hold the camera until the camera stops recording.
• When you take a picture using a large picture size setting, the screen will become
dark for a certain period of time after the picture is taken. However, this occurs due to
signal processing and is not a defect.
●
Notes on the [Soft Focus] setting
• The recording screen is displayed with a slight delay when compared to usual
recording. (When this effect is set, the recorded motion picture is played back like a
frame dropping.)
• When you take a picture using a large picture size setting, the screen will become
dark for a certain period of time after the picture is taken. However, this occurs due to
signal processing and is not a defect.
■
Changing the selected picture effects ([Creative Control] menu)
Press [MENU/SET]
Use cursor button to select [Creative Control] menu and press [MENU/SET]
Press to select a setting, and then press [MENU/SET]
■
Recording motion pictures in
Records a motion picture at the optimum settings for the selected effects.

Panasonic Lumix DMC-TZ30 Specifications

General

Megapixel	14.1 MP
Camera type	Compact camera
Sensor type	Live MOS
Image stabilizer	Yes
Total megapixels	15.3 MP
Image sensor size	1/2.33 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	4320 x 3240 pixels
Still image resolution(s)	480 x 480, 640 x 360, 640 x 424, 640 x 480, 1536 x 1536, 1920 x 1080, 1920 x 1920, 2048 x 1360, 2048 x 1536, 2304 x 2304, 2560 x 1440, 2560 x 1712, 2560 x 1920, 2736 x 2736, 3072 x 1728, 3072 x 2048, 3072 x 2304, 3232 x 3232, 3648 x 2056, 3648 x 2432, 3648 x 2736, 4320 x 2432, 4320 x 2880, 4320 x 3240
Digital zoom	4 x
Optical zoom	20 x
Extra/Smart zoom	42.2 x
Focal length range	4.3 - 86 mm
Maximum aperture number	6.4
Minimum aperture number	3.3
Number of aspheric elements	3
Lens structure (elements/groups)	12/10
Maximum focal length (35mm film equiv)	480 mm
Minimum focal length (35mm film equiv)	24 mm
Focus	TTL
Focus adjustment	Auto
Normal focusing range	0.5 - ∞/2 - ∞ m
Auto focusing (AF) modes	Continuous Auto Focus, Tracking Auto Focus
Macro focusing range (tele)	1 - ∞ m
Macro focusing range (wide)	0.03 - ∞ m
Normal focusing range (tele)	2 - ∞ m
Normal focusing range (wide)	0.5 - ∞ m
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, Auto
Light exposure modes	Aperture priority AE, Manual, Shutter priority AE
ISO sensitivity (max)	6400
ISO sensitivity (min)	100
Light exposure control	Program AE
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	15 s
Flash modes	Auto, Forced off, Forced on, Red-eye reduction, Slow synchronization
Flash range (tele)	1 - 3.3 m
Flash range (wide)	0.6 - 6.4 m
Digital SLR	No
Power source type	Battery
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	AVCHD, M-JPEG, MOV, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio system	Mono
Internal memory	12 MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3 \
Display resolution (numeric)	460000 pixels
USB version	2.0
Product color	Silver
Scene modes	Children, Night landscape, Night portrait, Panorama, Portrait, Sports, Sunset, Underwater, Landscape (scenery)
Image editing	Crop, Resizing
Photo effects	Black&White, Sepia, Vivid
White balance	Auto, Cloudy, Daylight, Incandescent, Shade
Shooting modes	Auto, Movie, Program, Scene
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 10 s
Camera file system	DCF, Exif 2.3
On Screen Display (OSD) languages	DEU, ENG, ESP, FRE, ITA, JPN
Battery voltage	3.6 V
Battery capacity	895 mAh
Battery life (CIPA standard)	260 shots
Cables included	USB

Weight and Dimensions

Depth	28.2 mm
Width	104.9 mm
Height	58.9 mm
Weight	184 g
Weight (including battery)	206 g
