Panasonic Lumix LX7 User Manual

Preparations
Names and Functions of Main Parts
- 10 - VQT4J15
10 Aperture ring
Adjusts the aperture value. (→60, 62)
11 Microphone
Records sound when you record motion
pictures. (→82)
12 Zoom lever
Adjusts the recording range. (→92)
13 Motion picture button
Press this button to start and stop motion
picture recording. (→46)
14 Camera ON/OFF switch
Turns the camera on or off.
15 Shutter button
Press this button to record a still picture.
(→46)
16 Flash open switch
Operate this switch to open the flash. (→106)
17 Tripod mount
Attach a tripod or other accessories to this
receptacle.
Do not attach to a tripod with a 5.5 mm or
longer screw. Doing so may damage this
unit.
18 Speaker
Do not cover the speaker with your fingers.
19 DC coupler cover
Use the AC adaptor (optional) and DC
coupler (optional) specifically for this
camera. (→205)
20 Card/Battery door
Open this door to insert and remove a card
or battery. (→18)
21 Release lever
Slide this lever to open the card/battery
door. (→18)
10 11 12 13
16 15 14
17 18 19 20
21

Panasonic Lumix LX7 Specifications

General

Sensor Type	MOS
Sensor Size	1/1.7-inch
Effective Pixels	10.1 MP
Lens	Leica DC Vario-Summilux
Optical Zoom	3.8x
Aperture	f/1.4 - f/2.3
Shutter Speed	60 - 1/4000 sec
Display	3.0-inch LCD
LCD Screen Resolution	920, 000 dots
Video Recording	Full HD 1920 x 1080
Video Format	AVCHD, MP4
Storage Media	SD/SDHC/SDXC Memory Card
Dimensions	110.5 x 67.1 x 45.6 mm
Focal Length	4.7 - 17.7 mm
ISO Sensitivity	80 - 6400 (Extended: 80-12800)
Image Stabilization	Optical Image Stabilization
Battery Type	Lithium-Ion Battery Pack
Battery Life	Approx. 330 images
Weight	298 g (including battery and memory card)
