B : BLUE
BR : BROWN
BL : BLACK
GRY : GRAY
W : WHITE
R : RED
O : ORANGE
P : PINK
Y/G : YELLOW/GREEN
Resistance of Indoor Fan Motor Windings
MODEL CS-A75KR CS-A95KR CS-
A125KR
CONNECTION
CWA921033CWA921032CWA921031
YELLOW-BLUE 707.1 451.2 450.7
YELLOW-
BROWN
71.1 86.7 68.2
BROWN-
ORANGE
64.7 98.4 56.7
ORANGE-
WHITE
15.7 51.5 56.9
WHITE-RED 116.2 240.8 102.0
Resistance of Outdoor Fan Motor Windings
MODEL CU-A75KR CU-A95KR CU-
A125KR
CONNECTION CWA95245 CWA95381
BLUE-YELLOW 260.5 174.5
YELLOW-RED 446.0 331.0
Resistance of Compressor Windings
MODEL CU-A75KR CU-A95KR CU-A125KR
CONNEC
- TION
2RS
122D5AB02
2PS
164D3AD02
2KS
224D5CA02
C-R 5.627 3.429 2.211
C-S 12.19 4.763 2.924
