Panasonic MAC0105011C3 - Electronic Parts List; Electronic Circuit Diagram

- All parts are supplied from MACC, Malaysia (Vendor Code: 086).
- “O” marked parts are recommended to be kept in stock.
21. Electronic Parts List
<Electronic Controller Part No.: CWA742320, CWA742327, CWA742313>
SYMBOL DESCRIPTION & NAME PART NO.
BZ1 SOUND GENERATOR A48040
CT1 TRANSFORMER A40322
D1, D4 DIODE A541SR154-4
D2 DIODE A54RB501V-40
D3 DIODE B0ACCK000005
DB1 DIODE A54CS1VB20E
FUSE FUSE XBA2C20TR0
FUSE HOLDER FUSE HOLDER K3GE1BA00015
IC1 INTEGRATED CIRCUIT A52D0022GB14
IC2 INTEGRATED CIRCUIT C3EBDG000021
IC3 INTEGRATED CIRCUIT A52A2003GR2
IC4 INTEGRATED CIRCUIT A52C040
IC5 INTEGRATED CIRCUIT A52C114
Q1 TRANSISTOR B1GBCFJJ0002
Q2, Q3 TRANSISTOR A55C2412KTX
Q4 TRANSISTOR A55D1484K
Q5 - Q8 TRANSISTOR B1GBCFGH0001
RY-HOT ELECTRO MAGNETIC RELAY A00161
RY-PWR ELECTRO MAGNETIC RELAY A001001
RY-SHi, RY-Hi, RY-M ELECTRO MAGNETIC RELAY A00160
SSR1, SSR2 TYRISTOR A56G3MC202PL
SW3 PUSH SWITCH EVQQKH08Q
T1 TRANSFORMER A401022
X1 RESONATOR A45CST4.09MG
ZD1 DIODE B0BC7R400003
ZNR1, ZNR2, ZNR3 DIODE ERZVEAV511
C-FM SH CAPACITOR A31499 (A95K), A31698 (
A75K,
A125K)
AC (WHT), HOT (RED), FM
(BLU)
TERMINAL BOARD A28069T
CR1, CR2, CR3, CR4, CR5 SURGE ABSORBER J0HBJY000003
Note
- All parts are supplied from MACC, Malaysia (Vendor Code: 086)
22. Electronic Circuit Diagram
