2-way Valve (Liquid Side) 3-way Valve (Gas
Side)
Works Shaft Position Shaft Position
Service
Shipping Close Closed
Closed
(With valve cap) (With valve cap) (
With
Evacuation Closed Closed
Open
(Installation and (Counter-Clockwise) (Clockwise) (
Push
Re-installation)
Operation Open Open
Closed
(With valve cap) (With valve cap) (
With
Pumping down Closed Open
Open
(Transferring) (Clockwise) (Counter-
Clockwise)
(
Connected
manifold
Evacuation Open Open
Open
(Servicing) With
vacuum
Gas charging Open Open
Open
(Servicing) (With
charging
cylinder)
Pressure check
Open
(Servicing) Open Open (
Connected
manifold
61
