36
TEMPERATURE RECORDER (OPTION)
Installation of MTR-G85C and MTR-85H
A temperature recorders is available for the freezer as the optional component. The type of the
temperature recorder is MTR-85H or MTR-G85C. For the attachment, optional component is necessary
as follows.
Temperature recorder Recorder fixing
MTR-85H
MTR-G85C
MDF-S3085
-----
Contact our sales representative or agent for the installation of a temperature recorder.
BACKUP COOLING KIT (OPTION)
Following shows the time to keep chamber temperature at -70
o
C by using an optional backup cooling kit.
Keep a liquefied CO
2
cylinder at ambient temperature lower than 31
o
C.
• The above data is the experiment value which uses liquid CO
2
30L. (no-load)
Ambient temperature (
o
C)
Time (h)
