Panasonic MDF-U74V - PERFORMANCE DATA

42
PERFORMANCE
Product name Ultra-Low Temperature Freezer
MDF-U74V
Model number MDF-U74V-PE
Cooling performance -86
o
C at the center of the chamber (ambient temperature; 30
o
C, no load)*
Temperature control range -50
o
C to -86
o
C (ambient temperature; 30
o
C, no load)
Power source AC 230 V/240 V, 50 Hz
Rated power consumption 1120 W/1170W
Noise level 51 dB [A] (background noise; 20 dB)
Maximum pressure 2680 kPa
Product name Ultra-Low Temperature Freezer
MDF-U55V
Model number MDF-U55V-PE
Cooling performance -86
o
C at the center of the chamber (ambient temperature; 30
o
C, no load)*
Temperature control range -50
o
C to -86
o
C (ambient temperature; 30
o
C, no load)
Power source AC 230 V/240 V, 50 Hz
Rated power consumption 650 W/700W
Noise level 47 dB [A] (background noise; 20 dB)
Maximum pressure 2030 kPa
Note : *: Maximum cooling performance.
The chamber temp. can be reached at –86
o
C at ambient temp. 30
o
C with noload.
