Panasonic NA-F60A6

- 2 -
CONTENT
Page
3
4 - 5
6 - 7
8 - 9
10 - 11
12
13 - 15
16 - 18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
35
36
36
1. Attention in the Repair Work Security
2. Specification
3. Features and Technical Information
4. Installation
5. Operations Panel
6. Wiring Diagram
7. Table of Errors
8. Troubleshooting
9. Parts Exploded View and Replacement Parts List
9.1 Parts Exploded View : A
9.2.1 Replacement Parts List : A for NA-F60A6
9.2.2 Replacement Parts List : A for NA-F70A6 / NA-F756A
9.2.3 Replacement Parts List : A for NA-F70G6 / NA-F70G6P
9.2.4 Replacement Parts List : A for NA-F70X6 / NA-F806X
9.3 Parts Exploded View : B
9.4.1 Replacement Parts List : B for NA-F60A6
9.4.2 Replacement Parts List : B for NA-F70A6 / NA-F756A
9.4.3 Replacement Parts List : B for NA-F70G6 / NA-F70G6P
9.4.4 Replacement Parts List : B for NA-F70X6 / NA-F806X
9.5 Parts Exploded View : C
9.6.1 Replacement Parts List : C for NA-F60A6
9.6.2 Replacement Parts List : C for NA-F70A6 / NA-F756A
9.6.3 Replacement Parts List : C for NA-F70G6 / NA-F70G6P
9.6.4 Replacement Parts List : C for NA-F70X6 / NA-F806X
9.7 Parts Exploded View : Packing
9.8.1 Replacement Parts List : Packing for NA-F60A6
9.8.1 Replacement Parts List : Packing for NA-F70A6 / NA-F756A
9.8.1 Replacement Parts List : Packing for NA-F70G6 / NA-F70G6P
9.8.1 Replacement Parts List : Packing for NA-F70X6 / NA-F806X
NA-F60A6, F70A6, F756A, F70G6, F70G6P, F70X6, F806X
Usage : For repairs and change of spare part only for washing machine type Panasonic Model
NA-F60A6 / NA-F70A6 / NA-F756A / NA-F70G6 / NA-F70G6P / NA-F70X6 / NA-F806X
Instructin for
Usage
: The work repair and changing of space part should be operated by a skilled technician from
the distribution agents or Panasonic’s Standard Service Center.
Warning : Switch off electrical power before commencing work to avoid a potential short circuit or injury.
