Panasonic NA-FS16X3

Model No.
NA-FS16X3
NA-FS14X3
Contents
Safety Precautions
2
Part Names
3
Operation Panel
4
Variety of Programs
5
Detergent
6
Washing
7
Washing Options
8
 Comforter
 Gentle Hand Wash
 Air Dry
 Wash / Rinse / Spin
Convenient Functions
10
Maintenance
10
Installation
12
Troubleshooting
14
Error Display
15

16
Thank you for purchasing this
product.
- Read these instructions carefully for
optimum performance and safety
before use.
- Keep this manual for future
reference.
Operating & Installation
Instructions
Fully Automatic Washing Machine
(Domestic use)
W9901-9MG40
T0915-0
Printed in Thailand
September 2015

Panasonic NA-FS16X3 Specifications

General

Type	Top Load Washer
Capacity	16 kg
Spin Speed	700 RPM
Washing Method	ActiveFoam System
Motor Type	Inverter Motor
Water Level Selection	10 Levels
Voltage	220-240 V
Frequency	50 Hz
Color	White
Wash Programs	10

Summary

Safety Precautions

Power Plug and Cord Safety

Guidelines for safe use and handling of the washing machine's power plug and cord.

Child Supervision and Usage Restrictions

Instructions regarding children's use and supervision of the appliance.

Fire and Explosion Hazard Prevention

Warnings about keeping flammable materials away from the appliance.

Spinning Tub Safety

Caution to avoid touching the tub until it has completely stopped spinning.

Grounding and Electrical Safety

Importance of proper grounding to prevent electric shock.

Prohibition of Self-Repair

Instructions to stop use and seek professional repair for malfunctions.

Magnetic Interference Warning

Advice to keep magnets away from the operation panel to prevent injury.

Part Names and General Usage

General Usage Warnings

Key warnings against washing specific items and improper appliance use.

Lid and Finger Safety

Caution to prevent fingers from being caught when opening/closing the lid.

Hose Set Recommendation

Guidance on using new hose-sets and not reusing old ones.

Water Faucet Management

Instruction to turn off the water faucet after operation to prevent leakage.

Appliance Suitability

Statement indicating the appliance is for textiles labelled machine washable.

Operation Panel Overview

Water Level and Time Display

Explanation of the display for water amount and remaining time.

Program Selection and Control

Details on setting programs, timer presets, and process adjustments.

Touch Operation and Notes

Information on touch controls, auto-restart, and automatic power-off.

Variety of Programs

Standard Washing Programs

Descriptions of common programs like Normal, Energy Save, Water Save, Baby-care, Fragrance.

Special Washing Programs

Details on programs for Comforters, heavy soil, delicates, and tub cleaning.

Laundry Preparation Checks

Guidance on pre-laundry checks, washing separately, and using laundry nets.

Detergent, Bleach, and Softener Usage

Detergent Addition Guidelines

Instructions on where to put detergent and notes on foaming.

Bleach Usage Instructions

Advice on using chlorine bleach and post-bleach tub cleaning.

Softener Addition Guide

How to add softener, including dilution for concentrated types.

Washing Procedure

Pre-Washing Steps

Checking installation, turning on the faucet, and powering on the machine.

Starting and Monitoring Wash

How to start the wash, check water amount, and add detergent.

Post-Start Adjustments

Options to change water level or cycle settings after starting.

Fragrance Program Specifics

Notes on adding softener during the Fragrance program.

Washing Options and Programs

Comforter Program Details

Material requirements and loading instructions for the Comforter program.

Gentle Hand Wash Program

Instructions for using the Gentle Hand Wash program with a washing board.

ECONAVI Functionality

Explanation of the ECONAVI feature, lamp indications, and how to switch it.

Load the Laundry

Guidelines on loading laundry evenly and using laundry nets.

Air Dry and WashRinseSpin Programs

Air Dry Program

How to use the Air Dry function and its limitations.

WashRinseSpin Process

Steps for starting and adjusting the Wash/Rinse/Spin cycle.

Convenient Functions and Maintenance

Cancelling End Buzzer

Procedure to press buttons to cancel or reset the end buzzer.

Setting Child Lock

How to activate and deactivate the Child Lock feature for safety.

Turning the Tub by Hand

Method to turn the tub manually, for example, to reach the detergent inlet.

Lint Filter Maintenance

Steps for removing, cleaning, and reattaching the lint filter.

Maintenance and Cleaning

Water Supply Filter Cleaning

Procedure to clean the water supply filter if water flow is reduced.

Tub Cleaning Programs

Instructions for running Air Dry and Tub Hygiene programs for cleaning.

Cleaning the Main Unit and Lid

Tips for wiping the main unit and lid with a soft cloth.

Softener Case Cleaning

Guide on how to remove and wash the softener case.

Installation Guide

Location Check

Advice on choosing a suitable and safe location for installation.

Bottom Cover Attachment

Steps for attaching the bottom cover using guides and a screw.

External Drain Hose Attachment

Instructions for correctly connecting and routing the drain hose.

Installation and Setup

Water Tap and Supply Hose Connection

Detailed steps for connecting the water tap adaptor and supply hose.

Power Plug and Grounding

Instructions for connecting the power plug and ensuring proper grounding.

Leveling the Washing Machine

How to adjust the legs to ensure the machine is level.

Performing a Trial Operation

Checks to perform during the initial trial run for leaks or sounds.

Troubleshooting Guide

Time Indication Issues

Troubleshooting for time indications that increase, decrease, or do not stop.

Operation and Power Issues

Resolving problems like no operation, unable to change settings, or power failure.

Water Supply and Level Problems

Addressing issues with no water supply, low/high water levels, or water not supplied after rinse.

Spin and Rotation Issues

Troubleshooting irregular rotation during spin or sudden changes to rinse.

Program Selection Issues

Resolving inability to select specific programs like Fragrance.

Error Display Codes

Water Cannot Drain Error (U11)

Checks for drain hose issues like crushing, clogging, or incorrect height.

Lid Open Error (U12)

Guidance to close the lid if the machine was operated with it open.

SpinAir Dry Not Possible Error (U13)

Troubleshooting for uneven clothes distribution or unstable installation.

Water Cannot Be Supplied Error (U14)

Checks for water faucet, supply filter, or water outage.

Forcible Drain Error (U99)

Resolution for forcible draining due to lid open with Child Lock active.

Inspection Required Error (H)

Instructions to unplug and contact a service person for inspection.

Specifications and Disposal

Appliance Specifications

Technical details including voltage, power consumption, capacity, and dimensions.

Waste Electrical & Electronic Equipment Disposal

Information on proper disposal and recycling of the appliance according to e-waste rules.
