11.2. PARTS LIST
NOTE:
1. When ordering replacement part(s), please use part number(s) shown in this part list.
Do not use description of the part.
2. Important safety notice:
Components identified by
mark have special characteristics important for safety.
When replacing any of these components, use only manufacture’s specified parts.
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
1 F00067600CP CAUTION LABEL 1 CPH
1 F00069660AP CAUTION LABEL 1 RPH
2 F10019L10XPG BASE 1
3 F1008-1L40BS RUBBER FOOT 4
4 F10099M60SBP CABINET BODY 1
5 F200A9M50QP OVEN 1
6 A010T7R00SP FLAT TABLE (U) 1
7 F202K7R00BP ANTENNA STIRRER (U) 1
8 F20197J70XP ANTENNA BRACKET 3
9 F30206G30AP DOOR HOOK 1
10 F31366G30AP HOOK LEVER A 1
11 F31376G30AP HOOK LEVER B 1
12 F31386G30AP HOOK LEVER C 1
13 F400A9M80CP FAN MOTOR 1
14 F4008-1L70 FAN BLADE 1
15 F64377J70XP GLASS 1
19 F41449M60BP UPPER ORIFICE 1
20 F4146-1P00 LOWER ORIFICE 1
21 F612E5Y30AP INCANDESCENT LAMP (U) 1
22 J61415G10XN MICRO SWITCH 1 (PRIMARY LATCH SWITCH)
23 F61415U30XN MICRO SWITCH 1 (SECONDARY LATCH SWITCH)
25 F61785U30XN MICRO SWITCH 1 (MONITOR INTERLOCK SWITCH)
26 2M261-M32JLP MAGNETRON 1
29 F62308F00AP FUSE 1 20A
31 F607X9M80CP NOISE FILTER (U) 1 CPH
31 F607X9M80RP NOISE FILTER (U) 1 RPH
32 F81247Q70BP BREAKWATER 1
34 F61449Q30AP STIRRER MOTOR 1
35 F900C9M80CP AC CORD W/PLUG 1
37 F00338F00AP FUSE LABEL 1
40 F630G9M50QP HEATER 2
41 F1161-1P00 REINFORCEMENT BRACKET A 1
42 F11659M60BP REINFORCEMENT BRACKET B 1
43 F61456V50HP THERMAL CUTOUT 1
44 F61457J70XP THERMAL CUTOUT 1
47 XTWBFE4+8D SCREW 4 FOR CABINET BODY
48 XTT4+8RDN SCREW 4 FOR MAGNETRON
49 F22379M60BP LEFT HEATER PANEL 1
50 F22369M60BP RIGHT HEATER PANEL 1
51 F4027-1P00 INVERTER AIR GUIDE 1
52 F606Y8X00AP H.V.INVERTER (U) 1
53 F60749M80CP INCANDESCENT LAMP BRACKET 1
54 F65859L00XP INVERTER BRACKET 1
57 F62389Q30AP COVER 1 CPH
58 F03349M80CP MENU LABEL 1 CPH
58 F03349M80RP MENU LABEL 1 RPH
59 F00067C50CP CAUTION LABEL 1 CPH
63 F01508G60HP NO TOUCHING LABEL 1
65 F22189M50QP UPPER HEATER PANEL 1
68 F10599M60BP BACK COVER 1
33
NN-CF770M
