12.2. PARTS LIST
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ310 L0DDEA000014 BUZZER 1 2.0KHz
C584 F2A1C100B624 CHEM CAPACITOR 1 10µF/16V
C10 F2A1H471B551 AL CHEM CAPACITOR 1 470µF/35V
C14 F2A1C220B624 AL CHEM CAPACITOR 1 22µF/16V
C225 F1B3A102A049 CERAMIC CAPACITOR 1
CX320 H2A8004A0038 CERAMIC RESONATOR 1 8.0MHz
DISP110 L5AYAYY00058 LCD 1
DISP HOLDER F66179M60BP LCD HOLDER 1
F67529L60XP DIFFUSION SHEET 1
D40,D41,D224,D227,D229,D230,D
584
B0AACK000004 DIODE 7
D10-D13 B0EAKT000025 DIODE 4
D585 B0JAAE000001 DIODE 1
D26,D27 D4EAY112A036 ZENER RESISTOR 2 1100V
IC1 MNE31G9M8CP L.S.I. 1
IC10 C0DAGYY00041 IC 1
IC200 B1HBGFF00007 IC 1
IC221 B3PAC0000060 IC (SSR) 1
Q180 B1BAAJ000003 TRANSISTOR 1
R311 D0AE102JA155 CARBON FILM RESISTOR 1 1KΩ,1/4W,5%
R10 D0AE103JA155 CARBON FILM RESISTOR 1 10KΩ,1/4W,5%
R290 D0AE104JA155 CARBON FILM RESISTOR 1 100KΩ,1/4W,5%
R220 D0AE331JA155 CARBON FILM RESISTOR 1 330Ω,1/4W,5%
RY1 AEBGJQC25F18 POWER RELAY 1
RY2,RY5,RY7 K6B1AZA00010 POWER RELAY 3
RY4,RY6 K6B1AZA00016 POWER RELAY 2
T10 G4C3AAD00006 LOW VOLTAGE TRANSFORMER 1 120V
VZ490 D3BB6103A006 VARISTOR 1 10KΩ
ZD10 B0BA5R600016 ZENER DIODE 1
RE81 EVEJ1HF2224B REVOLVING ENCODER 1
SW1-SW8,SW11-SW13,SW15-SW17 EVQ11L05R SWITCH 14
