Panasonic NN-GD577M - Parts List for Digital Programmer Circuit

5.3. PARTS LIST
5.3.1. NN-GD577M, SD577M
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ310 L0DDEA000014 BUZZER 1 2.0KHz
C10 AECETK1V561B AL CHEM CAPACITOR 1 560µF/35V
C13 AECETS1C220B AL CHEM CAPACITOR 1 22µF/16V
C482 AECETS1H010B AL CHEM CAPACITOR 1 1µF/50V
C483 AECETS1HR47B AL CHEM CAPACITOR 1 0.47µF/50V
C485 AECETS1H2R2B AL CHEM CAPACITOR 1 2.2µF/50V
CX320 H2B8004A0008 CERAMIC RESONATOR 1 EXCEPT YTE (8.0MHz)
CX320 H1A8004A0014 CRYSTAL RESONATOR 1 YTE (8.0MHz)
DISP110 L5AAAFD00027 LCD 1
DISP1 HOLDER F66178B80ZP LCD HOLDER 1
F67525E40XN DIFFUSION SHEET 1
D10-D13 B0EAKT000025 DIODE 4
D40,D220-D224,D226-D228 MA2C19600E DIODE 9
D25 D4EAY511A036 VARSITOR 1 510V
D26,D27 D4EAY112A036 VARSITOR 2 1100V
IC1 MN101C54CJK L.S.I. 1
IC480 C0ABBA000230 IC 1
Q10,Q180 B1BAAJ000003 TRANSISTOR 2
R10,R11,R311 D0AE102JA155 CARBON RESISTOR 3 1K,1/4W,5%
R12,R180 D0AE103JA155 CARBON RESISTOR 2 10K,1/4W,5%
R290 D0AE104JA155 CARBON RESISTOR 1 100K,1/4W,5%
RY1 AEBGJQC25F18 POWER RELAY 1
RY3 AEBGJQC25F18 POWER RELAY 1 GD557M
RY2 K6B1AZA00011 POWER RELAY 1
T10 G4C3AAH00008 LOW VOLTAGE TRANSFORMER 1
ZD10 B0BA5R600016 ZENER DIODE 1
RE80,RE81 EVEJ1HF2224B REVOLVING ENCODER 2
5.3.2. NN-GT547W
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ310 L0DDEA000014 BUZZER 1 2.0KHz
C10 AECETK1V561B AL CHEM CAPACITOR 1 560µF/35V
C13 AECETS1C220B AL CHEM CAPACITOR 1 22µF/16V
CX320 H2B8004A0008 CERAMIC RESONATOR 1 EXCEPT YTE (8.0MHz)
CX320 H1A8004A0014 CRYSTAL RESONATOR 1 YTE (8.0MHz)
DISP110 L5AAAFD00027 LCD 1
DISP1 HOLDER F66178B80ZP LCD HOLDER 1
F67525E40XN DIFFUSION SHEET 1
D10-D13 B0EAKT000025 DIODE 4
D40,D220-D224,D226-D228 MA2C19600E DIODE 9
D25 D4EAY511A036 VARSITOR 1 510V
D26,D27 D4EAY112A036 VARSITOR 2 1100V
IC1 MN101C54CJL L.S.I. 1
Q10,Q180 B1BAAJ000003 TRANSISTOR 2
R10,R11,R311 D0AE102JA155 CARBON RESISTOR 3 1K,1/4W,5%
R12,R180 D0AE103JA155 CARBON RESISTOR 2 10K,1/4W,5%
R290 D0AE104JA155 CARBON RESISTOR 1 100K,1/4W,5%
RY1,RY3 AEBGJQC25F18 POWER RELAY 2
RY2 K6B1AZA00011 POWER RELAY 1
T10 G4C3AAH00008 LOW VOLTAGE TRANSFORMER 1
ZD10 B0BA5R600016 ZENER DIODE 1
21
NN-GD577M / NN-SD577M / NN-GT547W
08/07
S-8B7
