1 SCHEMATIC DIAGRAM 5
1.1. APH
5
1.2. CPH
6
1.3. RPH
7
2 MEASUREMENTS AND ADJUSTMENTS
8
2.1. Adjustment of primary latch switch, secondary latch switch
and short switch.
8
2.2. Measurement of microwave output
8
3 PROCEDURE FOR MEASURING MICROWAVE ENERGY
LEAKAGE
9
3.1. Equipment
9
3.2. Procedure for measuring radiation leakage
9
3.3. Record keeping and notification after measurement
9
3.4. At least once a year, have the radiation monitor checked
for calibration by its manufacturer.
9
4 SIMPLE WAY OF H.V. INVERTER/MAGNETRON
TROUBLESHOUTING
10
5 EXPLODED VIEW AND PARTS LIST
11
5.1. EXPLODED VIEW
11
5.2. PARTS LIST
12
5.3. WIRING MATERIALS
13
5.4. ESCUTCHEON BASE ASSEMBLY
14
5.5. PACKING AND ACCESSORIES
20
5.6. DOOR ASSEMBLY
21
6 DIGITAL PROGRAMMER CIRCUIT
22
6.1. NN-P795 CPH, P794*FR APH/CPH
22
6.2. NN-T795SF APH/CPH, T795SF/SM RPH, T785SF APH
24
6.3. NN-T755SF APH, T794SFR APH, T774SFR APH
26
6.4. NN-T775SF/T765SF/T745SF/T735SF APH, T764SFR
APH
28
6.5. NN-H765 APH/CPH, H735 APH, S755 APH
30
6.6. NN-S735 APH
32
6.7. NN-S755 RPH
34
6.8. NN-S754*FR APH
36
6.9. PARTS LIST
38
