8.2. PARTS LIST
NOTE:
1. When ordering replacement part(s), please use part number(s) shown in this part list.
Do not use description of the part.
2. Important safety notice:
Components identified by
mark have special characteristics important for safety.
When replacing any of these components, use only manufacture’s specified parts.
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
1 F00067600CP CAUTION LABEL 1
2 F00336Z20AP FUSE LABEL 1
3 F10096Z00SCP CABINET BODY (U) 1 SD291S
3 F10098Q00HAP CABINET BODY (U) 1 SD291W
4 F100D6Z00AP BASE PLATE (U) 1
5 F201A6F10AP OVEN (U) 1
6 F20115H00AP COVER 1
7 F21314Y00XN PULLY SHAFT 1
8 F290D5Q00AP ROLLER RING (U) 1
10 F393C6Z00CP DOOR HOOK (U) 1
14 F40016Z00AP FAN MOTOR A 1 FOR INVERTER (U) COOLING
15 F40085H00AP FAN BLADE 1 FOR INVERTER (U) COOLING
16 F40256Z80AP ORIFICE 1
17 F401W9D90AP BLOWER MOTOR (U) 1
18 F42486Z00AP FAN CASE C 1
20 F42505H00AP SIROCCO FAN C 1
21 F42676Z80AP FAN MOTOR B 1 FOR MAGNETRON COOLING
22 F601L6F00AP SENSOR (BU) 1
23 F40246Z00AP EXHAUST GUIDE A 1
24 F44775H00AP EXHAUST GUIDE 1
25 F20025H00AP RACK SUPPORT 4
26 F65856Z00AP INVERTER BRACKET 1
27 F62386Z00AP WASHER 1
28 F62386F00AP WASHER 1
32 F100T5H00APG BACK PLATE (BU) 1
33 F400B6Z00AP FILTER (U) 2
34 F400K5H00APG EXHAUST ADAPTER 1
35 F63176F00SAP LAMP HOLDER 1 SD291S
35 F63175H10HAP LAMP HOLDER 1 SD291W
36 F64375H00AP GLASS PLATE 1
37 F41576Z00APG FAN INSTALLATION PLATE 1
38 F42176Z00APG COVER PLATE 1
39 F42205H00APG COVER PLATE B 1
40 F607V6Z00AP LAMP COVER (U) 1
41 F61846Z00AP GROUNDING PLATE 1
42 F60405H00AP LAMP MEMBRANE 1
43 F61446Z00AP STIRRER MOTOR 1
44 F20155H00AP STIRRER 1
45 F20165H00AP ANTENNA SUPPORT 1
46 F60305H00AP INCANDESCENT LAMP 1 (TOP OVEN LAMP)
48 F61525H00AP SOCKET 1
51 F61456F20AP THERMAL CUTOUT 1
52 F61456N60AP THERMAL CUTOUT 3
53 F606Y8X00AP H.V.INVERTER (U) 1
54 2M261-M32JP MAGNETRON 1
55 F62308F20AP FUSE 1 20A/125V
56 F400B6Z20AP CARBON FILTER (U) 1
57 F607X9X00CP NOISE FILTER (U) 1
58 F82605H00AP NOISE FILTER BRACKET 1
59 F66986Z20AP MOTOR CAPACITOR 1
60 F63266Z80AP TURNTABLE MOTOR 1
18
NN-SD291S / NN-SD291W
