9.2. PARTS LIST
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
BZ210 L0DDEA000014 BUZZER 1 2.0KHz
C10 F2A1C471B626 AL CHEM CAPACITOR 1 470µF/16V
C25 F2A2E4700009 CHEM CAPACITOR 1 47µF/250V
C11 F2A1C220B624 AL CHEM CAPACITOR 1 22µF/16V
C28 F2A1H1R0B574 AL CHEM CAPACITOR 1 1µF/50V
C490 F2A1J100A556 CHEM CAPACITOR 1 10µF/63V
C30,C31 F1BAH1020013 CERAMIC CAPACITOR 1 100PF/400V
C26 AECT81F102K CERAMIC CAPACITOR 1 1000PF/1KV
CX320 H2A8004A0038 CERAMIC RESONATOR 1 8.0MHz
DISP110 L5AYAYY00145 LCD 1
DISP HOLDER F66175W00AP LCD HOLDER 1
F67525E40XN DIFFUSION SHEET 1
D25,D41,D145-D149,D150,D220-
D223,D226,D227
B0AACK000004 DIODE 14
D11 AESB2100TLRC DIODE 1
D28 B0HAMT000018 DIODE 1
D29 B0HAMM000106 DIODE 1
D30 B0EDKR000014 BRIDGE DIODE 1
D31 B0EAKT000025 DIODE 1
D32 D4EAY271A036 ZENER RESISTOR 1 270V
ZD10,ZD11 DZ2J062M0L ZENER DIODE 2
ZD12 DZ2J068M0L ZENER DIODE 1
D490 B0AADM000003 DIODE 1
D491,D500 B0JAAE000001 DIODE 2
D130-D136 AE3294UBCA7 LED 7
IC1 MN101E29GJT L.S.I. 1
IC10 C0DBAHD00013 IC 1
IC25,IC27 B3PAA0000302 IC 2
IC26 MIP2K30MSSCF IC 1
IC220 B1HBGFF00007 IC 1
IC380 C3EBDC000063 IC 1
IC501 C0ABBA000230 IC 1
Q135,Q180 B1BAAJ000003 TRANSISTOR 2
D501 B0JAAE000001 DIODE 1
RY1 AEBGJQC25F12 POWER RELAY 1 12V
RY2-RY8 K6B1AGA00119 POWER RELAY 7
RY9 K6B1CGA00099 POWER RELAY 1
T10 G4DYA0000326 LOW VOLTAGE TRANSFORMER 1 120V
RE80,RE81 EVEJ1HF2224M REVOLVING ENCODER 2
SW40-SW47,SW49-SW56 EVQ11L05R SWITCH 16
26
