Panasonic NN-SD291S - 8.4. ESCUTCHEON BASE ASSEMBLY

8.4. ESCUTCHEON BASE ASSEMBLY
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
E1 F603L9X00CP D.P.CIRCUIT (AU) 1
E2 F603Y9X00CP D.P.CIRCUIT (DU) 1
E3 F800L9X00SCP ESCUTCHEON BASE (U) 1 SD291S
E3 F800L9X00HCP ESCUTCHEON BASE (U) 1 SD291W
E4 F66166Y40BP FLAT CABLE 1
E5 F82988Q00SAP BUTTON 1 SD291S
E5 F82989D90HAP BUTTON 1 SD291W
E6 F891P6F00SAP DOOR OPENING BUTTON (U) 1 SD291S
E6 F891P6Z00HAP DOOR OPENING BUTTON (U) 1 SD291W
E7 F82566F00AP DOOR OPENING LEVER 1
E8 F80375950AP COOK BUTTON SPRING 2
E10 F81278Q00APG BACK PANEL 1
E11 F83928P00KAP DIAL 2 SD291S
E11 F83929D90HAP DIAL 2 SD291W
E14 F80098P00AP LED COVER A 2
E15 F00079X00SCP NAME PLATE 1 SD291S
E15 F00079X00HCP NAME PLATE 1 SD291W
E16 XTWFNE4+12P SCREW 1 SD291S
E16 XTWFNE4+12PW SCREW 1 SD291W
21
NN-SD291S / NN-SD291W
