No.
Item/Part Fig. Removal (Screw & Other)
4. Lens Unit Fig. 7 1-Screw(N)
Disconnect the FP701/
PP201.
Remove the Lens Unit.
5. Mecha. Unit
& Main/
Front/ DSC
Ex In (NV-
DS28EN/
ENC/ENT/A,
DS37, NV-
DS38only)
C.B.A.s.
Fig. 8 Disconnect the FP4801/
FP6301.
Remove the Mecha. Unit &
Main C.B.A..
Disconnect the
PS3901.Remove the DSC
Ex In C.B.A..
Unlock---(b)
Remove the Front C.B.A..
6. Rear Case
Unit & Main
C.B.A.
Fig. 9 Remove the Battery Case
Unit(Disconnect P1001)
1-Screw(O)
Disconnect the following
connectors.
FP5001/FP2203/FP2201/
FP2202 Unlock---(c)
Remove the MainC.B.A..
7. LCD Unit Fig.
10
2-Screws(P)
Unlock---(d)
Remove the LCD Case
(Upper).
Disconnect the FP903.
Unlock---(e)
Remove the LCD Unit from
Side Case (R) Unit.
Fig.
11
Remove the Back Light
Unit,Insulation Sheet and
Monitor C.B.A..
8. EVF C.B.A. Fig.
12
Remove the EVF Flex.
2-Screws(Q)
Remove the EVF Unit.
Fig.
13
Unlock---(f)
Remove the Eye Cap
Holder and Eye Cap.
Fig.
14
Unlock---(g)
Remove the EVF Case
(Upper) and (Lower).
Fig. 1
14
