Panasonic NV-DS37B - Frame & Casing Section (2) Parts List

Ref. No. Part No. Part Name & Description Remarks
101 VKF3342 EVR COVER
102 VYK9973 EVF CASE (UPPER)
103 VKM5571 EVF CASE (LOWER)
104 VYQ2165 EVF VIEW ADJ. U.
105 L5EDDXH00005 EVF LCD PANEL
106 VGQ5492 EVF PROTECT SHEET
107 VGQ6265 PROTECT COVER SHEET
108 VGQ6143 LCD MASK
109 VJF1422 LCD HOLD PIECE
110 VJF1423 LCD HOLD COVER
111 LSFL0039 LED LENS
112 LSFL0040 LED DIFFUSION SHEET
113 VGQ6172 EVF PROTECT TAPE
114 VMG1383 EYE CAP
115 VWJ1470 EVF FLEX.
116 VYK9863 EVF SLIDE CASE U.
117 VKM5569 TOP CASE
118 VMP6786 ACCESSORY SHOE
119 VYK9861 FRONT CASE U.
120 VYF2765 LENS HOOD U.
121 N9ZZ00000094 SIDE CASE (R) (1) U. NV-DS27 NV-DS28
121 N9ZZ00000097 SIDE CASE (R) (1) U. NV-DS37 NV-DS38
B101 VHD1303 SCREW
B102 VHD1303 SCREW
B103 XQN16+B4FN SCREW
B104 XQN16+B4FN SCREW
B105 XQN16+B4FN SCREW
B106 XQN16+B4FN SCREW
B107 XQN16+B4FN SCREW
B108 XQN16+BJ6FN SCREW
B109 XQN16+BJ6FN SCREW
B110 XQN16+BJ5FZ SCREW
B111 XQN16+BJ5FZ SCREW
B112 XQS2+A55FN SCREW
B113 XQS2+A55FN SCREW
B114 XQS2+A55FN SCREW
B115 XQN2+BJ10FN SCREW
B116 XQN2+BJ10FN SCREW
14.2. FRAME & CASING SECTION (2) PARTS LIST
