Panasonic NV-DS37B - Page 84

No. Item Fig. Oil &
Grease
Procedure
14 TR Band & TR Arm U. Fig. 11-
1
- Connect TR Arm and TR Band
Fig. 11-
2
- 1) Make full unloading condition with 3V ba
t
/ 2) Install TR Arm U.
Fig. 11-
3
- Adjust Tension
Fig. 11-
4
-
Fig. 11-
5
-
15 Cylinder U. Fig. 12-
1
- 1) Make full unloading condition with 3V ba
t
/ 2) Install Cylinder U.
Fig. 12-
2
- Turn the mechanism and install Cylinder
Spring, then tighten 3 screws(E)
Fig. 12-
3
- Tighten 1 screw(F) for Cylinder Flex. Cable
16 Mechanism Flexible Cable Fig. 13 - Solder each terminal
17 Garage U. Fig. 14-
1
Oil 1) Engage joints(C) at S and T sides (*T sid
e
first).
Fig. 14-
2
- 2) Engage joints(B) at both S and T sides
18 Dumper Fig. 15 - Install Dumper
The following parts should be applied the Oil (VFK1700) or Grease (VFK1298A).
14
