14.1. FRAME & CASING SECTION
(1) PARTS LIST
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
3 VYK1L54 EVF VIEW ADJ.U 1
4 VGQ8313 SLIDE CASE HOLDER 1
5 VGQ7249 SLIDE SPACER 1
6 VGQ7249 SLIDE SPACER 1
7 VGQ8314 EVF COVER PIECE 1
8 VGQ7689 PLATE HOLDING
PIECE
1
9 VGL1136 LENS PANEL 1
10 VMP8211 EVF PLATE 1
11 VGQ8284 LCD HOLD PIECE 1
12 VMC1951 EVF CLICK SPRING 1
13 L5BDDXH00014 EVF PANEL 1
14 VGQ8346 LCD HOLD PIECE 1
15 VGL1145 BL PANEL 1
16 VGL1144 EVF DIFFUSION
SHEET
1
17 VGQ7102 BL PIECE 1
19 VGQ8312 EVF PIECE 1
20 VWJ1767 EVF FPC 1
21 VMP8208 SR PLATE 1
23 VWJ1753 R FPC 1
24 VGQ8280 KNOB HOLDER 1
25 VGU9729 MODE CHANGE KNOB 1
26 VMP8224 EVF FRAME 1
27 VXA7975 HINGE PLATE U 1
28 VMP8207 TRIPOD PLATE 1
30 VGL1142 PANEL LIGHT 1
32 VMC1956 SD DOOR SPRING 1
33 VGL1142 PANEL LIGHT 1
34 VYK1L75 SIDE CASE (R) 1U 1
35 VMS7564 SD SHAFT 1
36 VKF3968 SD DOOR 1
40 VGL1036 TALLY PANEL LIGHT 1
42 VGK3085 FRONT DECORATION 1
43 VKW3265 SENSOR WINDOW 1
44 VGK3086 LENS DECORATION 1
46 VMG1672 LENS DUMPER GUM 1
47 VDW0911 MF PLATE 1
48 VYK1L82 LENS HOOD U 1
49 VMP8225 ADD NET ANGLE 1
50 VGQ8315 MIC ADDNET 1
51 VKM6656 FRONT CASE 1
52 VGQ6816 SHEET 1
53 VMP8226 MIC ANGLE 1
54 VMT1405 MIC GUM 1
55 VEP04886A TALLY/ECM FPC U 1
B1 XQN16+B3FN SCREW 1
B5 VHD1775 SCREW 1
B6 VHD1775 SCREW 1
B7 VHD1642 SCREW 1
B8 VHD1642 SCREW 1
B10 VHD1393 SCREW 1
B11 VHD1393 SCREW 1
B12 XQN16+B2FN SCREW 1
B13 XQN16+BJ6FN SCREW 1
B14 XQN16+BJ6FN SCREW 1
B15 XQN16+BJ6FN SCREW 1
B16 XQN16+BJ6FN SCREW 1
B17 XQN16+BJ4FJK SCREW 1
B18 XQN16+BJ35FN SCREW 1
B19 XQN16+BJ35FN SCREW 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
B20 XQN16+BJ35FN SCREW 1
B21 XQN16+B3FN SCREW 1
B22 XQN16+B3FN SCREW 1
B23 XQN16+B3FN SCREW 1
B24 XQN16+B3FN SCREW 1
B25 XQN16+BJ6FN SCREW 1
B26 XQN16+BJ35FN SCREW 1
B27 XQN16+BJ6FN SCREW 1
B28 XQN16+B3FN SCREW 1
B32 XQN16+BJ5FN SCREW 1
B33 XQN16+BJ5FN SCREW 1
B34 XQN16+BJ5FN SCREW 1
B38 XQN16+B3FN SCREW 1
B39 VHD1411 SCREW 1
B40 VHD1411 SCREW 1
14.2. FRAME & CASING SECTION
(2) PARTS LIST
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
101 N9ZZ00000286 SIDE CASE (L) 1U 1
102 N9ZZ00000289 REAR OPERATION U 1
103 VKF3963 EVR COVER 1
105 VWJ1752 JACK FPC 1
106 VKF3965 MECHANISM
ADJ.COVER
1
107 VGQ6407 SHEET 1
109 VGQ8318 SENSOR HOLDER 1
B101 XQN16+B5FN SCREW 1
B102 XQN16+B5FN SCREW 1
B103 XQN16+B5FN SCREW 1
B104 XQN16+B6FN SCREW 1
B105 XQN16+BJ3FN SCREW 1
B106 XQN16+B3FN SCREW 1
B107 VHD1133 SCREW 1
B108 VHD1133 SCREW 1
B109 VHD1133 SCREW 1
B110 VHD1353 SCREW 1
B111 XQN16+B3FN SCREW 1
B112 XQN16+BJ6FN SCREW 1
B113 XQN16+B3FN SCREW 1
B114 XQN16+BJ4FN SCREW 1
B115 XQS2+A4FN SCREW 1
B116 XQS2+A4FN SCREW 1
B117 XQS2+A4FN SCREW 1
14.3. LCD SECTION PARTS LIST
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
201 VYK1L77 LCD CASE (T) U 1 E,EB,EG,EK,EP
201 VYK1M46 LCD CASE (T) U 1 GC,GCD,GN
201 VYK1M49 LCD CASE (T) U 1 GK
202 VKM6655 LCD CASE (B) 1
203 VSC5681 LCD SHIELD CASE 1
204 VUALCD150KIT LCD (MONITOR) 1
205 VGQ8351 MONITOR SHEET 1
206 VGL1147 PRISM SHEET A 1
207 VGL1148 PRISM SHEET B 1
14 REPLACEMENT PARTS LIST
55
NV-GS75E / NV-GS75EG / NV-GS75EB / NV-GS75EK / NV-GS75EP / NV-GS75GC / NV-GS75GN / NV-GS75GCD / NV-GS78GK
