Panasonic NV-GS75E - Camera Lens Section Parts List; Vcr Mechanism Section Parts List; Packing Parts & Accessories Section Parts

Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
208 VGL1109 SHEET 1
209 VKW3178 POLARIZATION PLATE 1
210 VGL1143 REFLECTION SHEET 1
212 VXD0443 LCD HINGE (1) U 1
213 VGQ8392 HINGE COVER (B) 1
214 VGQ8311 HINGE COVER (T) 1
215 VGQ8445 LCD PORON 1
B201 VHD1675 SCREW 1
B202 VHD1675 SCREW 1
14.4. CAMERA LENS SECTION
PARTS LIST
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
301 VXQ1311 PRISM U 1
302 VMX3456 CUSHION 1
303 VDL1646 CRYSTAL OPTICS
FILTER
1
304 VXW0701 LENS U 1
305 VDW1109 MASTER FLANGE 1
306 VXP2431 4TH MOVING FRAME U 1
307 VXQ1309 3RD MOVING FRAME U 1
308 L6HA64NC0002 FOCUS MOTOR U 1
309 VXP2434 IRIS U 1
310 VMS7312 GUIDE POLE 1
311 VMS7312 GUIDE POLE 1
312 VXP2429 2ND MOVING FRAME U 1
313 VXQ1308 LENS MAIN FRAME U 1
314 L6HA64NC0001 ZOOM MOTOR U 1
B301 XQN16+CJ5FJ SCREW 1
B302 XQN16+CJ5FJ SCREW 1
B303 XQN16+CJ7FJ SCREW 1
B304 XQN16+CJ7FJ SCREW 1
B305 XQN16+CJ7FJ SCREW 1
B306 XQN16+CJ5FJ SCREW 1
B307 XQN16+CJ5FJ SCREW 1
B308 XQN16+CJ5FJ SCREW 1
B309 XQN16+CJ5FJ SCREW 1
B310 XQN16+CJ5FJ SCREW 1
B311 XQN16+CJ5FJ SCREW 1
B312 XQN16+CJ5FJ SCREW 1
14.5. VCR MECHANISM SECTION
PARTS LIST
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
501 VXA8014 MECHA. CHASSIS 1
501-4 VXR0403 T REEL U 1
503 VXA7932 CASSETTE UP U 1
503-1 VMB3766 CASSETTE UP SPRING 1
503-2 VMB3766 CASSETTE UP SPRING 1
504 VEG1663 CYLINDER U 1
B501 VHD1632 SCREW 1
B502 VHD1757 SCREW 1
B503 VHD1757 SCREW 1
B504 VHD1757 SCREW 1
B505 VHD1754 SCREW 1
B506 VHD1754 SCREW 1
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
B507 VHD1755 SCREW 1
14.6. PACKING PARTS &
ACCESSORIES SECTION
PARTS LIST
Note:
“EN”, “SP”, “GE”, “FR”, “IT”, “SW”, “DU”, “DA”, “RU”, “CZ”,
“PR”, “AR”, “CN”, “PE” inthe Part Name & Description
column shows writing language as follows.
“EN”: ENGLISH
“SP”: SPANISH
“GE”: GERMAN
“FR”: FRENCH
“IT”: ITALIAN
“SW”: SWEDISH
“DU”: DUTCH
“DA”: DANISH
“RU”: RUSSIAN
“CZ”: CZECH/HUNGARIAN
“PR”: PORTUGUESE
“AR”: ARABIC
“CN”: CHINESE (SIMPLIFIED)
“PE”: PERSIAN
Ref.
No.
Part No. Part Name &
Description
Pcs Remarks
401 VPG1B37 PACKING CASE 1 E,EB,EG,EK,EP
,GC,GCD,GN
401 VPG1B36 PACKING CASE 1 GK
402 VPN6272 CUSHION 1
403 VPK2940 ACCESSORIES BOX 1
404 VFC3506-1A SHOULDER BELT 1
405 K2GJ2DZ00017 DC CABLE 1
406 K2KC4CB00018 AV CABLE 1
407 K2CQ2DA00003 AC CORD 1 E,EG,EK,EP,GC
,GCD
407 RJA0053-3X AC CORD 1 EB,GC,GCD
407 K2CJ2DA00008 AC CABLE 1 GN
407 K2CA2CA00020 AC CORD 1 GK
408 N2QAEC000012 REMOTE CONTROLLER 1
409 VYF3031 HOOD CAP U 1
410 N2QCAD000002 UNIVERSAL 1
REMOTE CONTROLLER
411 VFA0425B USB CABLE 1 E,EB,EG,EK,EP
,GC,GCD,GK
411 VFQ0425B USB CABLE 1 GN
412 VQT0N55 OPERATING
INSTRUCTIONS
1 E
(PR/SP)
412 VQT0N56 OPERATING
INSTRUCTIONS
1 E
(SW/DA)
412 VQT0N57 OPERATING
INSTRUCTIONS
1 EB
(EN)
412 VQT0N53 OPERATING
INSTRUCTIONS
1 EG,EK
(GE/FR)
