2x Optical Zoom Lens
The 2x optical zoom lens provides a wide
throw range that gives you outstanding setup
flexibility, letting you enjoy large-screen view-
ing in different sized rooms. Position it on a
table in front of you, suspend it from the
ceiling, or place it on a bookshelf behind you.
Vertical and Horizontal Lens Shift
Adjust the positioning of the picture vertically
and horizontally by simply operating a joy-
stick. The shift range is 63% of the screen
height for vertical adjustment, and 25% of
the screen width for horizontal adjustment.
Two HDMI Inputs
Two HDMI inputs let you
connect two devices, such
as a BD player and game console, at the
same time, using HDMI cables. This elimi-
nates the need for an HDMI switcher.
Simple, Convenient Remote Control
The remote control is intu-
itively laid out for ease of
use. The picture mode
select buttons are divided
into “Theatre Room” and
“Living Room” to separate
the modes into those rec-
ommended for dark room
viewing and bright room
viewing respectively.
Other Features
• Seven picture modes include game, vivid
cinema, normal, dynamic, cinema 1, cinema
2 and natural. • User equalising function
lets you adjust the high, mid and low gamma
levels. • Up to eight sets of adjustment set-
tings can be stored in memory with custom
names that make them easy to remember.
• Scene-adaptive residing LSI improves quali-
ty when residing 480p images or those from
other sources with resolution lower than the
PT-AX200’s native resolution. • Cinema
Colour Management allows individual colour
correction • Scene-adaptive MPEG noise
reduction effectively blocks regular noise and
minimises mosquito noise. • 24p compatible
• Progressive cinema scan (3/2 pulldown)
and HD IP • Quiet operation (25 dB) and
front exhaust • On-screen input guidance
• Auto input search • Off-timer
• Normal/economy lamp power selection
• Built-in test pattern
PT-AX200E Specifications
Power supply
Power consumption
LCD panel*
1
Panel size
Aspect ratio
Display method
Pixels
Lens
Lamp*
2
Brightness*
3
Contrast*
3
Resolution
YP
BPR signal compatibility
Colour system
Optical axis shift*
5
Keystone correction range
Terminals
HDMI IN
COMPUTER IN
COMPONENT IN
S-VIDEO IN
VIDEO IN
SERIAL
Dimensions*
6
(W x H x D)
Weight
Operating environment
Supplied accessories
Optional accessories
ET-LAX100
ET-PKX200
ET-ADSER
100–240 V AC, 50/60 Hz
290 W (Approx. 0.08 W in standby mode with fan stopped)
0.7˝ (17.78 mm) diagonally
16:9 aspect ratio
Transparent LCD panel (x 3, R/G/B)
921,600 (1280 x 720) x 3, total of 2,764,800 pixels
Manual zoom (2x)/Manual focus, F 1.9 - 3.1, f 21.7 mm - 43.1 mm
220 W UHM™ lamp
2,000 lumens*
4
6,000:1*
4
(full on/full off)
RGB: 1280 x 720 pixels (1920 x 1080 pixels with compression)
480i (525i), 480p (525p), 576i (625i), 576p (625p), 720 (750)/50p, 720 (750)/60p, 1,080
(1,125)/24p, 1,080 (1,125)/50i, 1,080 (1,125)/50p, 1,080 (1,125)/60i, 1,080 (1,125)/60p
NTSC, NTSC 4.43, PAL, PAL-M, PAL-N, PAL 60, SECAM
Horizontal ±25% and vertical ±63%
Vertical: approx. ±30°
HDMI connector x 2
D-sub HD 15-pin (female) x 1
RCA pin (Y, P
B/CB, PR/CR) x 1
Mini DIN 4-pin x 1
RCA pin x 1
Mini DIN 8-pin x 1 (RS-232C based)
395 x 112 x 300 mm (15-17/32˝ x 4-13/32˝ x 11-25/32˝)
4.9 kg (10.8 lbs.)
Temperature: 0°–40°C (32°–104°F), Humidity: 20%–80% (no condensation)
Power cord, Wireless remote control unit, Batteries for remote control (AA type x 2)
Replacement lamp unit
Ceiling mount bracket
Serial adapter (DIN 8-pin/D-sub 9-pin)
*1: The projector uses a type of liquid crystal panel that typically consists of
millions of pixels. This panel is built with very high-precision technology
designed to provide one of the finest possible images. Occasionally, a few
pixels may remain turned on (bright) or turned off (dark). Please note that
this is an intrinsic characteristic of the manufacturing technology that
affects all products using LCD technology.
*2: The projector uses a high-voltage mercury lamp that contains high internal
pressure. This lamp may break, emitting a large sound, or fail to illumi-
nate, due to impact or extended use. The length of time that it takes for
the lamp to break or fail to illuminate varies greatly depending on individ-
ual lamp characteristics and usage conditions.
*3: Measurement, measuring conditions, and method of notation all comply
with ISO 21118 international standards.
*4: In AI mode, with dynamic iris on
*5: Shift range is limited during simultaneous horizontal and vertical shifting.
*6: Excluding protrusions
For detailed explanation of features please visit our Projector Global Web Site http://panasonic.co.jp/pavc/global/projector
Image Size/Projection Distance
