Technical Information
ENGLISH - 49
Appendix
Terminals
S-VIDEO IN
Single - line, Mini DIN 4p Y: 1.0 V [p-p], C: 0.286 V [p-p], 75
Ω
VIDEO IN
Single - line, RCA pin jack1.0 V [p-p], 75
Ω
COMPUTER IN
Single - line, D - sub HD 15-pin (female)
R.G.B.
0.7 V [p-p], 75
Ω
G.SYNC
1.0 V [p-p], 75
Ω
HD/SYNC
TTL high impedance, automatic
positive/negative polarity
compatible
VD
TTL high impedance, automatic
positive/negative polarity
compatible
COMPONENT IN
Y, P
B/CB, PR/CR Single - line, RCA pin jack x 3
Y:
1.0 V [p-p] (including sync), 75
Ω
PB/CB, (PR/CR)
0.7 V [p-p], 75 Ω
HDMI IN Dual - line, 19-pin HDMI connector
SERIAL DIN 8-pin RS-232C compatible
Cabinet Moulded plastic (PC+ABS)
Dimensions
Width 395 mm (15 -17/32")
Height 112 mm (4 -13/32")
Length 300 mm (11 -25/32")
Weight 4.9 kg (10.8 lbs.)
Certifications EN60950-1, EN55022, EN61000-3-2, EN61000-3-3, EN55024
Remote control
Power supply 3 V DC (AA battery x 2)
Operating range Approx. 7 m (23') (when operated directly in front of signal receptor)
Weight 125 g (4.4 ozs.) (including batteries)
Dimensions
Width 48 mm (1 -7/8")
Length 138 mm (5 -13/32")
Height
28.35 mm (1 -3/32")
(not including surface projection
parts)
Options
Ceiling bracket ET-PKX200
Projection screen ET-SRW90CC
Cables
ET-SC10CP (RCA pin jack x 3 - RCA pin jack x3)
ET-SC10DT (RCA pin jack x3 - D-Terminal)
Serial adapter ET-ADSER (DIN 8-pin/D-sub 9-pin)
